MC14094BDR2G Onsemi Counter Shift Registers
Parameter
| Manufacturer |
onsemi |
| Product Category |
Counter Shift Registers |
Series
|
MC14094B
|
| Logic Family |
MC14 |
| Logic Type |
CMOS |
| Supply Voltage-Max |
18 V |
| Output Type |
3-State |
Minimum Operating Temperature
|
-55 C |
Maximum Operating Temperature
|
+125 C |
| Operating Supply Voltage |
3 V to 18 V |
Packaging
|
Reel/Cut Tape
|
Factory Pack Quantity
|
2500 |
Introduction
The MC14094BDR2G offers a compact and efficient solution for digital signal conditioning, providing high noise immunity and low power consumption. The hex Schmitt trigger is designed to operate over a wide temperature range (-55°C to +125°C) and can handle a maximum voltage of 18 V.
The MC14094BDR2G features a compact and robust SOIC-14 (Small Outline Integrated Circuit) package, making it easy to mount on a printed circuit board. Additionally, the chip incorporates advanced features, such as hysteresis and Schmitt trigger action, making it well-suited for use in a wide range of digital applications that require reliable and accurate signal conditioning.
