MC7805CTG Onsemi Linear Voltage Regulators
Parameter
| Manufacturer |
onsemi |
| Product Category |
Linear Voltage Regulators |
Series
|
MC7805
|
| Output Voltage |
5 V |
| Output Current |
1 A |
| Input Voltage,Min |
7 V |
| Input Voltage,Max |
35 V |
Minimum Operating Temperature
|
0 C |
Maximum Operating Temperature
|
+125 C |
Packaging
|
Tube
|
Factory Pack Quantity
|
50 |
Introduction
The MC7805CTG offers a compact and efficient solution for power regulation, providing a fixed output voltage of 5 V with a maximum output current of 1 A. The voltage regulator is designed to operate over a wide temperature range (-40°C to +125°C) and can handle a maximum input voltage of 35 V.
The MC7805CTG features a compact and robust TO-220 package, making it easy to mount on a printed circuit board. Additionally, the chip incorporates advanced features, such as thermal overload protection and short-circuit protection, making it well-suited for use in a wide range of power management applications that require reliable and robust voltage regulation.
Application
The MC7805CTG is widely used in various industries, including automotive, industrial, and consumer electronics. As a linear voltage regulator IC, it is commonly used in power management applications, such as power supplies, voltage regulators, and battery chargers. Its fixed output voltage of 5 V and maximum output current of 1 A make it an ideal component for regulating power in a wide range of electronic systems. Additionally, the chip's ability to operate over a wide temperature range (-40°C to +125°C) and handle a maximum input voltage of 35 V make it well-suited for use in harsh environments. The MC7805CTG's thermal overload protection and short-circuit protection features make it a reliable and safe choice for power management applications. Overall, the MC7805CTG is a versatile and reliable linear voltage regulator IC that can be used in a wide range of applications across different industries where stable and reliable power regulation is crucial.
