Overview
Brand Name: Huawei
Product Number: 3054629
Model Number: ME0DBSUF5170
Discription: Huawei ME60 Series Multi-Service Control Gateways ME0DBSUF5170 Flexible Card Broadband Service Unit(BSUF-51,2 sub-slots).
Product Series: ME60-X8
Huawei ME60 50G flexible broadband service board (BSUF-51,2 sub-slots).
Provides two 1/2-width slots, and each slot holds one FPIC.
FPIC supports Hot swap, Automatic recovery of configurations and Intermixing with other types of FPICs.
Huawei ME0DBSUF5170 is a flexible broadband service board (BSUF-51,2 sub-slots) applied to Huawei ME60, enhances networking flexibility and provides low-cost and customized solutions supports packet forwarding at the line speed of 50 Gbit/s, also provides two 1/2-width slots, and each slot holds one FPIC.
Functions and features
|
Functions and Features
|
Remarks
|
|
Line-Rate capability
|
Supports 50G line-rate processing of
broadband services.
|
|
Slot information
|
The board provides a maximum of two
half-width slots and each slot can hold one FPIC card.
|
|
Reliability and availability
|
Hot swappable
|
Board specifications
|
Item
|
Specification
|
|
Dimensions (H x W x D)
|
40.1 mm x 399.2 mm x 535.6 mm (1.58 in. x 15.72 in. x 21.09 in.)
|
|
Typical power consumption
|
180.0 W
|
|
Typical heat dissipation
|
583.5 BTU/hour
|
|
Weight
|
7.2 kg (15.88 lb )
|
|
Reliability and availability
|
Software features
-
Nonstop Forwarding (NSF)
-
MPLS Fast Reroute (FRR)
Hardware features
-
The BSUF-51 supports hot swap.
-
The FPIC of the BSUF-51 supports hot swap
|
|
NMS
|
Enhanced command-line interface
SNMP and MIB support
|
|
Operating conditions
|
Long-term ambient temperature: 0°C to
45°C (32°F to 113°F)
Short-term ambient temperature: -5°C to
+55°C (23°F to 131°F)
Long-term relative humidity: 5% to
85%
Short-term relative humidity: 5% to
95%
|
|
Storage conditions
|
Storage temperature: -40°C to +70°C
(-40°F to 158°F)
Storage humidity: 5% to 100%
|
|
Physical specifications
|
|
Dimensions(mm)
|
40.1(H)x 399.2(W) x 535.6(D)
|
|
Weight(kg)
|
7.15
|
|
Power consumption (typical value)(W)
|
180
|
|
