10KW HIGH FREQUENCY PREHEATER
High frequency preheating machine is mainly used for preheating process before molding thermosetting materials such as melamine, urea plastics, epoxy resin, phenolic resin, melamine, etc., which can enhance the fluidity of the material, reduce harmful ingredients, and improve the surface gloss of the product.
Application
kitchenware, tableware, electronic components, integrated circuits, electrical appliances and other industries.
Features
1. Motor type upper cover closing mechanism. Large opening angle of upper cover; correct locking position.
2. Easy operation, extremely convenient storage of raw materials, less adjustment parameters.
3. Multiple safety functions and equipment protection devices.
4. Three-layer dust filter protection device.
5. Widely using for the preheating of melamine large products or UF toilet cover &seats.
Technical Parameters
|
No
|
Content.
|
HGY-1020
|
|
1
|
Output
|
10KW
|
|
2
|
Power Source
|
3Φ220V
380V
415V
|
|
3
|
Power Input
|
20KVA
|
|
4
|
Oscillation Frequency
|
27MHZ
|
|
5
|
Vacuum Tube
|
8T85RB
|
|
6
|
Voltage Switching
|
3-stage
|
|
7
|
Time
|
999.9S
|
|
8
|
Preheating Power
|
110℃ Within 60 secs
|
|
9
|
Phenolic Resin
|
6500gr
|
|
10
|
Melamine Moulding
Compound
|
6000gr
|
|
11
|
Urea Moulding
Compound
|
6000gr
|
|
12
|
Electrode Size
|
450×560m/m
|
|
13
|
Electrode Spacing
|
35-60m/m
|
|
14
|
Machine Dimensions (W
D H)
|
820×1150×1720
|
|
15
|
Machine Weight
|
600kg
|
■ PS: Specifications subject to change without notice.
