Bearing No.
|
Dimensions(mm)
|
Ball
dia
|
a°
mis.
angle
|
Load ratings
(KN)
|
Weight
≈ kg
|
|
d
|
B
|
C1
|
d2
|
d3-6H
|
h1
|
L3
|
(L4)
|
L5
|
L7
|
d4
|
d5
|
w
|
Dynamic
|
Static
|
|
SI5E1)
|
5
|
6
|
4.5
|
21
|
M5
|
30
|
11
|
40.5
|
5
|
11.5
|
11
|
13
|
11
|
10
|
13
|
3.4
|
8.1
|
0.021
|
|
SI6E1)
|
6
|
6
|
4.5
|
21
|
M6
|
30
|
11
|
40.5
|
5
|
11.5
|
11
|
13
|
11
|
10
|
13
|
3.4
|
8.1
|
0.021
|
|
SI8E1)
|
8
|
8
|
6.5
|
24
|
M8
|
36
|
15
|
48
|
5
|
13
|
13
|
16
|
13
|
13
|
15
|
5.5
|
12.9
|
0.039
|
|
SI10E1)
|
10
|
9
|
7.5
|
29
|
M10
|
43
|
20
|
57.5
|
6.5
|
15
|
16
|
19
|
16
|
16
|
12
|
8.1
|
17.6
|
0.061
|
|
SI12E1)
|
12
|
10
|
8.5
|
34
|
M12
|
50
|
22
|
67
|
7
|
18
|
18
|
22
|
19
|
18
|
10
|
10
|
24.5
|
0.096
|
|
SI15ES
|
15
|
12
|
10.5
|
40
|
M14
|
61
|
30
|
81
|
8
|
21
|
21
|
26
|
21
|
22
|
8
|
16
|
36
|
0.162
|
|
SI17ES
|
17
|
14
|
11.5
|
46
|
M16
|
67
|
32
|
90
|
10
|
23
|
25
|
29
|
27
|
25
|
10
|
21
|
45
|
0.233
|
|
SI20ES
|
20
|
16
|
13.5
|
53
|
M20x1.5
|
77
|
38
|
103.5
|
10
|
25.5
|
28
|
34
|
30
|
29
|
9
|
30
|
60
|
0.324
|
|
SI25ES
|
25
|
20
|
18
|
64
|
M24x2
|
94
|
45
|
126
|
12
|
33
|
35
|
42
|
36
|
35.5
|
7
|
48
|
83
|
0.625
|
|
SI30ES
|
30
|
22
|
20
|
73
|
M30x2
|
110
|
54
|
146.5
|
15
|
37.5
|
42
|
50
|
46
|
40.7
|
6
|
62
|
110
|
0.976
|
|
SI35ES
|
35
|
25
|
22
|
82
|
M36x3
|
125
|
60
|
166
|
15
|
40
|
48
|
58
|
55
|
47
|
6
|
79
|
146
|
1.52
|
|
SI40ES
|
40
|
28
|
24
|
92
|
M39x3
|
142
|
65
|
188
|
18
|
47
|
52
|
65
|
60
|
53
|
7
|
99
|
180
|
2.06
|
|
SI45ES
|
45
|
32
|
28
|
102
|
M42x3
|
145
|
65
|
196
|
20
|
52
|
58
|
70
|
65
|
60
|
7
|
127
|
240
|
2.72
|
|
SI50ES
|
50
|
35
|
31
|
112
|
M45x3
|
160
|
68
|
216
|
20
|
57
|
62
|
75
|
70
|
66
|
6
|
156
|
290
|
3.57
|
|
SI60ES
|
60
|
44
|
39
|
135
|
M52x3
|
175
|
70
|
242.5
|
20
|
68.5
|
70
|
88
|
80
|
80
|
6
|
245
|
450
|
5.63
|
|
SI70ES
|
70
|
49
|
43
|
160
|
M56x4
|
200
|
80
|
280
|
20
|
81
|
80
|
98
|
85
|
92
|
6
|
313
|
610
|
8.33
|
|
SI80ES
|
80
|
55
|
48
|
180
|
M64x4
|
230
|
85
|
320
|
25
|
91
|
95
|
110
|
95
|
105
|
6
|
400
|
750
|
13.04
|
Can not be relubricated.
Can supply rod ends with different pitch or accuracy of thread.
For left-hand thread, suffix "L" is added to bearing numbers. e.g.:SIL20ES M20×1.5L-6H:
related products:Rod End Bearings
