Microwave Oven Door Endurance Tester

ZLT-WM1. To determine the endurance of the door system, including the hinges, microwave seals and other associated parts, shall be constructed to withstand wear that may be expected in normal use, according to the IEC60335-2-25 clause 18.

Facebook Twitter Pinterest LinkedIn 分享

Microwave Oven Door Endurance Tester


Product details: Model ZLT-WM1.


To determine the endurance of the door system, including the hinges, microwave seals and other associated parts, shall be constructed to withstand wear that may be expected in normal use, according to the IEC60335-2-25 clause 18.
The door is opened and closed as in normal use. It is opened from the closed position to an angle between 135° and 180° or the maximum possible angle, if this is less. The rate of operation is six cycles per minute.
Standard Outfit:
1 test frame, industrial molding Aluminum, maximum testing angle, 140°(open angle of microwave oven door), for horizontal or vertical sample forms,
1 electronic circuit with 10A plug for power below 2000W of the sample, with testing function, judge whether the current work, in the testing process, automatic stop if the sample no electricity work, counter displays test times and warning,
1 electronic predetermining pulse counter, 6-digit, to indicate the number of cycles and to disconnect the machine when reaching the preselected number of cycles.
Model ZLT-WM2, as type ZLT-WM1, but for 2 samples.
Power Supply: 220V 50Hz, other voltages on request.
