Military quality hot sale Beiben 6x4 5m3 capacity concrete mixer truck

Advantages
- One-stop shop, thousand kinds of products with military quality for you to choose
- Most competitive and reasonable price, ready to develop together with customer
- Reliable and effective performance, time=money
- Great after-sales service system, back you up all the time
Product Description
Beiben 5m3 concrete mixer truck ND5256GJBZ
|
Whole Vehicle Parameters
|
Chassis
|
BEIBEN
|
Curb weight (kg)
|
12780
|
Total vehicle weight (kg)
|
25000
|
Overall dimensions (L*W*H)
|
9400x2500x3900
|
Wheelbase (mm)
|
4100+1450
|
Front overhang (mm)
|
1410
|
Rear overhang (mm)
|
2640
|
Max. Traveling speed (km/h)
|
85
|
Vehicle Configuration
|
Clutch
|
Dry single dis clutch (Φ430)
|
Gearbox
|
FAST 9T-1680
|
Driving type
|
6x4
|
Steering mechanism
|
TAS85
|
Service brake
|
Dual-circuit air brake
|
Parking braking
|
Spring-powered Air-cut-off brake
|
Auxiliary brake
|
Engine exhaust brake
|
Tire
|
12.00R20 radial tire
|
Engine Parameters
|
Model
|
WP10.340E32
|
Feature
|
Diesel, 4 stroke,
Direct injection,
6 cylinder in line,
Turbo-charging, Inner cooling
|
Emission standard
|
Euro 3
|
Max power (kw)
|
340hp
|
Max torque (N.m)
|
1500
|
Mixing Drum Parameters
|
Max mixing cubage (m³)
|
5
|
Feeding speed (m³)
|
3.5
|
Discharging speed (m³)
|
3
|
Leftover rate
|
Nearly Zero
|
Max Rotating Speed (R/min)
|
14-16
|
Mixing Drum Obliquity (°)
|
10
|
Max mixing drum diameter (mm)
|
Φ2412
|
Driving System
|
Hydraulic Pump
|
Italian TOP089
|
Hydraulic Motor
|
TOP 089
|
Speed reducer
|
TOP P68
|
Water supply mode
|
Water pump; pneumatic pump
|






Beiben concrete mixer truck parts details for reference.
