Specification


LIGHT SOURCE

Lamp: Philips/Osram 200W

CT:8000K

Lifespan: 2,000H



OPTICS

Beam angle: 3.8°
High precision glass optic system

Improved optics and flat beam field



COLORS
1 Color wheel: 14 color+open

Half-color effect, linear color change, bidirectional rotating rainbow effect at variable speed



GOBOS
1 Static gobo wheel: 14 +open

Shakable and bi-directionally rotatable at variable speeds



MOVEMENT
Pan movement: 540° optional (16 bit )

Tilt movement: 270°(16 bit )
Advanced moving system: auto repositioning, fast, quiet and smooth



FEATURES

Rotating prism: 8/16/32 facet prism optional

Focus: motorized linear focus

Frost: 1 frost filter, soft and natural wash effect

Strobe: mechanical shutter, variable from 1-13Hz or random
Dimming: mechanical dimmer 0-100% linearly adjustable



DISPLAY

2.8 inch full color touch LCD display, show customer logo

15 second standby auto lock



SOFTWARE

Remote lamp control (on/off, ignited by inverter, protect and lengthen the lifetime of the bulb)

Control mode: DMX512, master-slave, auto-run, sound activate

Channel: 16/20 CH

Run time of lamp and fixture record



OTHER SPEC

Fixture and lamp usage time display

Highly positioning precision

Adjustable fan speed

Built-in analyzer for easy fault finding, error messages

Input signal isolating protection

Auto thermal protection circuit

Housing: high temperature UV resistant ABS



POWER
Voltage: AC100-240V, 50/60Hz

Power Consumption: 320w@220V

DIMENSIONS AND WEIGHT
Fixture dimension: 33*27*47cm

Packing dimension:

52x41x35cm(Carton)

74x35x62cm(2 in 1 flightcase)

Net Weight: 11.7kg

Gross Weight:

14kg(Carton)

43kg(2 in 1 flightcase)
