MINI COLOUR SORTER is specially designed by Scisort for processors who requires small handling capacity on rice, coffee beans, pulses. It is suitable for small processors, like farmers、coffee shops, academies and scientific research institutes.
The MINI range sorter has small footprint and it is moveable!
TECHNICAL CHARACTERISTICS
Camera System
Industrial grade biomimetic identification
system, suitable for a wide range of materials. Wide spectrum imaging ; Camera
pixel 5400, scanning frequency up to 1000 frames / sec. And it has image
capturing function.
Optical
System
Customize
industrial wide-angle lens, high sharpness and high brightness; large DOF &
low distortion, fully enhanced resolution. Reliable and steady temperature cold
LED lighting system.
Electric System
All electric components are world recognized brands, line Schneider, SMC, MeanWell etc. Safety and stability can be assured.
Power
Supply System
Wide range voltage, all DC drive and APFC
power supply, high stability and safety.
Feeding
System
High-voltage
DC and pulse width modulation (PWM) controlled feeding system, output
quantitatively controllable; Specially oxidized chutes, reduce the friction and
the material flow smoothly and the output is larger.
Ejection
System
The valve is made of ultra-low power
consumption material, adopts superconductivity technology and high frequency
switch; PWM control center identification technology, accurate blowing and lower
air consumption.
Dust Removal System (optional)
Intelligent dust removal system help to increase
yield.
APPLICATION
Rice, peanuts, white sesame seeds, wheat, corn, chinese medicinie slice, soybeans, sunflower seeds, raisins, medlar, coffee beans, dried shrimps, milky kidney beans, adzuki beans, etc.
Technical Data
|
Model
|
TD-0.5T-MI
|
|
Voltage
|
110~220V，50~60HZ
|
|
Channels
|
32
|
|
Power
|
Main
|
0.4 kw
|
|
Heater(optional)
|
0.4 kw
|
|
Air
Consumption
|
200~600 ltr/min
|
|
Throughput (rice)
|
300~600 kg/h
|
|
Weight
|
160KG
|
|
Dimension(LxDxH)(mm)
|
400x1100x1200
|
