Part Number: AJ65BT-D62D
Configured Specifications
Classification Differential Input Number of Channels(ch) 2
Count input signal level EIA standard RS-422-A differential type line driver level (equivalent to AM26LS31 (Texas Instruments Japan Limited)) Preset External Input DC5/12/24 V 2 to 5 mA
Computing Speed (1 Phase Input) HIGH side: 400kpps/Low side: 10kpps Computing Speed (2 Phase Input) HIGH side: 300kpps/Low side: 7kpps
Note Differential Input - Preset DC Input - Conforming Standards: UL/cUL CE (EMC) RoHS 6
CC-Link High-Speed Counter Unit Common Specifications
|
Ambient Operating Temperature
|
0 to 55β
|
|
Ambient Storage Temperature
|
-20 to 75β
|
|
Ambient Operating Humidity
|
10 to 90% RH, no condensation
|
|
Ambient Storage Humidity
|
10 to 90% RH, no condensation
|
|
Vibration Resistance
|
JIS B 3502, IEC 61131-2 Compliant
|
Under Intermittent Vibration
|
Frequency: 5 to 8.4 Hz, single amplitude: 3.5 mm
Frequency: 8.4 to 150 Hz, constant acceleration: 9.8 m/s2
Sweeps: 10 sweeps in each direction of X, Y and Z
|
|
Under Continuous Vibration
|
Frequency: 5 to 8.4 Hz, Single amplitude: 1.75 mm
Frequency: 8.4 to 150 Hz, Constant acceleration: 4.9 m/s2
|
|
Impact Resistance
|
JIS B 3502, IEC 61131-2 compliant
(147 m/s2, 3 times in each direction of X, Y and Z)
|
|
Operating Atmosphere
|
No corrosive gas
|
|
Operating Altitude
|
0 to 2,000 m
|
|
Installation Location
|
Inside the control panel
|
|
Overvoltage Category
|
II or lower
|
|
Pollution Degree
|
2 or less
|
