Mitsubishi Electric (MELSERVO J2S series) - Rated output 750W / 0.75kW - 17-bit (equivalent to 131072ppr) feedback - Rated current 5.1A - Supply voltage 200Vac class - Rated torque 2.4Nm nominal - Rated rotational speed 3000rpm - 80x80mm flange mounting - IP55 - rated for 0...+40°C ambient
| Primary brand |
Mitsubishi Electric |
| Main function |
AC servo motor |
| Product series / family name |
MELSERVO J2S series |
| Sub-range name |
HC-MF series |
| Functions |
AC brushless rotary servo motor |
| Design |
straight shaft
built-in absolute feedback encod. (17-bit)
ultra-low inertia / small power capacity |
| Supply voltage (AC) |
200Vac class |
| Rated current |
5.1A |
| Rated active power (kW) |
750W / 0.75kW |
| Rotational speed |
3000rpm
4500rpm (maximum) |
| Torque |
2.4Nm nominal |
| Maximum torque |
7.2Nm |
| Moment of inertia |
0.00006kg.m2 (0.6kg.cm2) |
| Mounting mode |
80x80mm flange mounting |
| Resolution |
17-bit (equivalent to 131072ppr) feedback |
| Degree of protection |
IP55 |
| Dimensions |
H98.1mm x W82mm x D182mm |
| Ambient air temperature for operation |
0...+40 °C |
| Ambient air temperature for storage |
-15°C...+70 °C |
| Maximum current |
18 A |
