Technical data
| Primary brand |
Mitsubishi Electric |
| Main function |
AC servo motor |
| Product series / family name |
MELSERVO J4 series |
| Sub-range name |
HG-RR series |
| Functions |
AC brushless rotary servo motor |
| Design |
straight shaft
built-in absolute feedback encod. (22-bit)
oil seal
ultra-low inertia / medium power capacity
natural cooling
|
| Supply voltage (AC) |
200Vac class |
| Rated active power (kW) |
1000W / 1kW |
| Rotational speed |
3000rpm
6000rpm (maximum)
|
| Moment of inertia |
0.00015kg.m2 (1.5kg.cm2) |
| Connection type |
MS-type connectors |
| Mounting mode |
100x100mm flange mounting |
| Resolution |
22-bit (equivalent to 4194304ppr) feedback |
| Degree of protection |
IP65 |
| Dimensions |
H144.8mm x W100mm x D190.5mm |
| Ambient air temperature for operation |
0...+40 °C |
| Ambient air temperature for storage |
-15°C...+70 °C |
| Maximum radial load |
686 N |
