Product details
Serial interface module, RS232 (D-sub 9-pin) - 1 channel
This remote module is intended to be installed near the control target and is suitable for use in wet environments.
The main advantages are reduced cabling and the capability of acquiring data and operation results of individual machine modules autonomously.
Technical specification
|
|
No. of inputs:
|
2
|
|
Isolation method:
|
Photocoupler
|
|
Rated input voltage:
|
24V d.c.
|
|
Rated input current:
|
Approx. 7mA
|
|
Operating voltage range:
|
19.2 to 28.8V d.c. (ripple ratio: 5% or less)
|
|
ON voltage/ON current:
|
14V/3.5mA or higher
|
|
OFF voltage/OFF current:
|
6V/1.7mA or lower
|
|
Input resistance:
|
Approx. 3.3kΩ
|
|
Response time:
|
|
|
OFF—ON:
|
10ms or lower
|
|
ON—OFF:
|
10ms or lower
|
|
Wiring method for common:
|
2 points/common (COM1)
Positive negative common shared type
|
|
External connection system:
|
7-point terminal block (M3.5 screw)
|
|
Network speed:
|
Up to 10Mbps
|
|
Network distance:
|
Up to 1.2km
|
Features:
-
Up to 64 I/O modules with a maximum of 32 inputs or 32 outputs each can be connected
-
Compact design which is tough and highly shock-resistant
-
IP67 - Suitable for wet environments
-
Status indicator LEDs for the inputs
-
Modules can be positioned in a horizontal arrangement or one of four orientations on a flat surface.
-
DIN rail or screw mounting
