60 cells 5BB Mono solar panel 270w/275w/280w/285w all with good quality for on-grid & off-grid solar power system
Electrical Characteristics (STC)
|
Module Type
|
DHM60-270
|
DHM60-275
|
DHM60-280
|
DHM60-285
|
|
Maximum Power (Pmax)
|
270W
|
275W
|
280W
|
285W
|
|
Open-circuit Voltage (Voc)
|
38.5V
|
38.8V
|
39.0V
|
39.3V
|
|
Maximum Power Voltage (Vmp)
|
31.5V
|
31.6V
|
31.7V
|
31.8V
|
|
Short-circuit Current (Isc)
|
9.17A
|
9.25A
|
9.35A
|
9.45A
|
|
Maximum Power Current (Imp)
|
8.57A
|
8.70A
|
8.83A
|
8.97A
|
|
Module Efficiency(%)
|
16.51%
|
16.82%
|
17.13%
|
17.43%
|
|
Power Tolerance
|
0~+5W
|
|
Standard Test Environment
|
Irradiance 1000W/m2, Cell Temperature 25℃，Spectrum AM 1.5
|
60 cells packing details
|
Container
|
20GP
|
40GP
|
40HC
|
|
Pcs/pallet
|
30
|
30
|
30
|
|
Pallet/container
|
14
|
28
|
28
|
|
Pcs/container
|
400
|
840
|
924
|
First-class solar panel warranty Reliable quality
1.10 years material & technology guarantee
2. 25 years linear power output guarantee
3. 100% Double full EL inspection
4. 0-+5W Positive power output guarantee
Product Characteristics
1. Excellent PID free performance.
DAH Solar’s DHM60 cells Series solar panel is PID Free module under the condition of 85℃/ 85% RH. It can be used for all applications, including Civil and commercial solar power systems.
2. Certified anti Salt-mist,anti ammonia corrosion performance, sand and storm test by TUV Rheinland and TUV Nord.
3. Excellent mechanical performance with 2400 Pa wind load and 5400 Pa snow load.
4. Outstanding weak light generating performance with good quality solar panels(morning,nightfall,cloudy & rainy day).
5. Anti-reflective glass not only increase light absorption,but also reduce the power loss by solar panels its self cleaning function under rainy environment.
More Products information pls contact with us mailto:sales@dh-solar.cn and visit our factory video
