advanced core patented technology
|
|
high safety, triple anti-pinch
|
|
high stability, optimize the mechanism structure
|
|
long life, longer than 5 million times
|
|
|
|
|
|
|
|
|
|
accurate & fast detection
|
|
high visitor flow rate usage
|
|
modular design, easy maintenance
|
|
high compatibility, high integration
|
Advanced & Intelligent Turnstile Core Technology
Advanced motor control technology
The turnstile adopts advanced servo control system, DSP+ARM motor control technology, combined with CMOLO's original motor control algorithm, to achieve precise control and positioning of the obstacles and maintain stable performance.
Advanced core logic algorithm
The flap barrier turnstile adopts CMOLO® patented passing detection algorithm and matrix photoelectric stereo detection technology, to sensitively detect illegal behaviors such as reversely passing and tailgating, and issues warnings in the form of sound and light, and can be linked with other security systems.
Strong mechanism structure
CMOLO has independently developed an advanced lossless mechanism structure, and is equipped with industrial grade brushless servo motor (core of the mechanism), so that the flap barrier turnstile has a long service life.
Long service life
The flap barrier turnstile's mechanism & control system have passed 5 million times life test.
All-around Pedestrian Safety Protection
Triple anti-clamping
With triple anti-clamping technologies such as infrared anti-clamping, mechanical anti-clamping and anti-collision by advanced electric current detection, the flap barrier turnstile can protect pedestrian safety more comprehensively.
Anti-electric shock
All electric modules are designed to operate under the safety voltage of 24V, and configured with residual current protective device to prevent pedestrian from being injured by electric shocks.
Turnstile opens when power failure
With the independently developed advanced mechanical structure, the system will automatically unlock the gate when the power is off, and the gate can be manually pushed to open, which is convenient for pedestrian evacuation.
Emergency open
The flap barrier turnstile equips with emergency escape control device, to make the system automatically open the flap to evacuate pedestrian.
Customization
| Appearance |
Cabinet size, material and surface treatment process etc. of flap barrier turnstile can be moderately customized. |
| System integration |
Integrate with access control system, human body temperature measurement system, ticketing system, time attendance system, visitor system etc.
Integrate with QR code, face, fingerprint, ID/IC card, passport identification system etc.
Integrate with card collection system, and customize card collection device
|
