MSP430F1101AIDWR TI 16 bit Microcontrollers - MCU
Parameter
| Manufacturer |
Texas Instruments |
| Product Category |
16-bit Microcontrollers - MCU |
| Mounting Style |
SMD/SMT |
| Package / Case |
SOIC-20 |
| Number of I/Os |
14 I/O |
Series
|
MSP430F1101A
|
Supply Voltage - Min
|
1.8 V
|
Supply Voltage - Max
|
3.6 V |
Minimum Operating Temperature
|
- 40 C
|
Maximum Operating Temperature
|
+ 85 C
|
| Data ROM Size |
128 B |
| Data ROM Type |
Flash |
Packaging
|
Reel/Cut Tape |
Factory Pack Quantity
|
2000 |
Introduction
The MSP430F1101AIDWR is a microcontroller chip developed by Texas Instruments as part of their MSP430 family of ultra-low-power microcontrollers. This chip is designed specifically for embedded applications that require low power consumption and high performance.
The MSP430F1101AIDWR features an advanced 16-bit RISC architecture with a wide range of integrated peripherals, making it suitable for a variety of applications, including industrial control systems, consumer electronics, and portable devices. It operates at a clock frequency of up to 16 MHz and is built on a low-power CMOS process technology, enabling efficient power management and extended battery life.
The chip incorporates 1KB of flash memory for program storage and 128 bytes of RAM for data storage. It also includes a 16-bit timer and a real-time clock module, enabling precise timing and event capture capabilities. The MSP430F1101AIDWR supports various communication interfaces, including UART, I2C, and SPI, allowing for seamless integration with other devices and peripherals.
One of the key features of the MSP430F1101AIDWR is its ultra-low power consumption. It offers multiple low-power modes, including standby and sleep modes, which significantly reduce power consumption during idle periods. This makes it ideal for battery-powered applications where power efficiency is critical.
The chip is housed in a small form factor package with 20 pins (TSSOP), making it suitable for space-constrained designs. It operates over a wide temperature range, allowing it to be deployed in harsh environments.
Application
The MSP430F1101AIDWR microcontroller chip finds wide industry applications due to its low power consumption and versatile features. It is commonly used in industrial control systems, consumer electronics, portable devices, and other embedded applications. With its 16-bit RISC architecture, integrated peripherals, and communication interfaces such as UART, I2C, and SPI, it enables seamless integration and efficient control in various devices. The chip's ultra-low power modes make it ideal for battery-powered applications, ensuring extended battery life. Its compact form factor and wide temperature range further enhance its suitability for space-constrained and harsh environments. Overall, the MSP430F1101AIDWR is a reliable choice for applications requiring low power consumption and high performance.
