Multi-axis SMD Electric LED Robotic Soldering Machine
1. The multi-axis robotic soldering machine has double heads and double tables for higher effciency, especially for led strips soldering.
2. Precisely feeds solder wire from 0.5 to 1.2mm diameter, optional 0.2mm, feeder is wire specific.
3. Program robot path, speed and all soldering conditions on teach pendant, up to 255 soldering conditions.
4. Tip temperature range to 450℃
5. The multi-axis robotic soldering machine ;has alarms: out of solder, solder jamming, heater control
SPECS:
|
Model
|
SMTSR223
|
|
Dimension
|
680*500*720mm
|
|
Weight
|
90Kg
|
|
Control
|
PLC
|
|
Programming
|
Teaching box
|
|
Driving mode
|
Stepper motor
|
|
Stroke
|
300(X)x300(Y1)x300(Y2)x80(Z)
|
|
Soldering head
|
2
|
|
Repeatability
|
±0.02mm(X/Y/Z)
|
|
Temp. Range
|
0-550℃
|
|
Solder Wire Spec
|
￠0.3-1.6mm
|
|
Number of axes
|
4
|
|
Working pressure
|
0.4~0.6Mpa(No water mist)
|
|
Power
|
AC110V/220V 300W
|
|
Display
|
LCD
|
FEATURES:
1. The ;multi-axis robotic soldering machine contains BASIC interpreter, simple programming, direct handle teaching, you can directly enter the welding point coordinates, but also teach welding position, can reproduce the welding position coordinates.
2. ;Using multi-axis robots and advanced motion control algorithms for linkage to simulate the action of human hand plus tin, effectively improving the positioning accuracy of the iron head.
3. ;The program has built-in multi-dimension soldering method, spot welding and drag welding. All process parameters can be set by the user. It can simulate various difficult and micro soldering processes of human hands.
4. ;With manual control of tin.
APPLICATIONS:
This multi-axis robotic soldering machine is suitable for automotive electronics, digital, electronic, electro-acoustic, LCD, circuit board and other production industries, connectors, networks, transformers, cable, FPC / COF soldering, computer motherboards, CABLE, speakers and motors high quality soldering.
CONFIGURATION:
1. ;Four-axis welding machine dual Y working platform
2. ;Handheld teach programmer
3. ;Heating controller
4. ;Broken tin controller
5. ;Soldering tip
6. ;Tin out components
7. ;Smoke purification filter system (optional)
Spare Parts Available:
1. Customized soldering tips
2. Heater
3. Customized fixture
4. Solder wire
5. Soldering head set
; ;
