About product:
|
Brand
|
|
|
Part Number
|
MVI46-DFNT
|
|
Product Type
|
Ethernet I/P Client / Server module
|
|
Payment
|
T/T,100% advance payment
|
|
Shipping Port
|
Xiamen,China
|
|
Lead Time
|
In stock
|
Description:
The MVI46-DFNT is an SLC500 module Ethernet I/P Client server / communication module. This module is an encompass partner module manufactured by Prosoft Technology. It has One (1) RJ45 port for Ethernet connection, One (1) RJ45 CFG Port and One (1) RJ45 RS232 Configuration connector. This module is a single slot module with backplane Current load of 800 mA @ 5V.
The MVI46-DFNT is an INRAX client/server communication module. The communication module is SLC-backplane compatible which enables SLC processors to be connected with devices using explicit messaging over an Ethernet/IP. With the industrial environment investing heavily in Ethernet/IP technology, the MVI46-DFNT provides a centralized point to simply interface the SLCs with Ethernet/IP network applications.
Specifications:
Part Number/Catalog No.:MVI46-DFNT
Product Type:Ethernet I/P Client / Server module
Backplane Current Load:800 ma @ 5V (from backplane)
Manufacturer:Prosoft Technology
Compatible Platform:SLC500
Compatible Controllers:SLC 5/02, M0/M1 processors
No. of Ports:Three (3) ports; CFG Port (CFG) / Configuration Connector / Ethernet I/P
Compatible Processors:Compatible with Rockwell Automation SLC 5/02 M0/M1 capable processors or newer
Module width:Single Slot
Operating Shock:30 g
Operating Vibration:5 g @ 10…500 Hz
Isolation Voltage: 50V (continuous), Basic Insulation Type, Fieldbus to system
Relative Humidity:5% to 95% (non-condensing)
