General
|
|
|
Device Type
|
Expansion module
|
|
Form Factor
|
Rack-mountable
|
|
Networking
|
|
|
Ports
|
Gigabit Ethernet x 48
|
|
Connectivity
Technology
|
Wired
|
|
Cabling Type
|
Ethernet 100Base-TX,
Ethernet 1000Base-T
|
|
Data Link
Protocol
|
100Mb LAN, GigE
|
|
Auxiliary
Ports
|
4 x SFP+ (uplink)
|
|
Network /
Transport Protocol
|
TCP/IP, UDP/IP,
ICMP/IP
|
|
Remote
Management Protocol
|
SNMP 1, SNMP 2, RMON,
SNMP 3
|
|
Status
Indicators
|
Port status, power,
system
|
|
Features
|
Flow
control, full duplex capability, uplink, hot swap module replacement,
auto-negotiation, VLAN support, IGMP snooping, Syslog support, Weighted Round
Robin (WRR) queuing, IPv6 support, Spanning Tree Protocol (STP) support,
Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames
support
|
|
Compliant
Standards
|
IEEE
802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE
802.1x, IEEE 802.3ae
|
|
Expansion /
Connectivity
|
|
|
Expansion
Slots
|
4 (total) / 4 (free)
x SFP+
|
|
Interfaces
|
48 x 1000Base-T -
RJ-45
|
|
Miscellaneous
|
|
|
Compliant
Standards
|
CISPR
22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, VCCI Class A ITE,
EN 61000-3-3, EN55024, EN55022 Class A, EN50082-1, EN 61000-6-1, AS/NZS
60950-1, ICES-003 Class A, RoHS, FCC CFR47 Part 15, EN300-386, UL 60950-1,
IEC 60950-1, EN 60950-1, CSA C22.2 No. 60950-1
|
|
Pricing Type
|
Refurbished
|
|
Power
|
|
|
Power Device
|
Power supply -
hot-plug / redundant - plug-in module
|
|
Voltage
Required
|
AC 120/230 V (50/60
Hz)
|
|
Power
Consumption Operational
|
110 Watt
|
|
Dimensions
& Weight
|
|
|
Width
|
17.3 in
|
|
Depth
|
17.7 in
|
|
Height
|
1.7 in
|
|
Weight
|
17.64 lbs
|
|
Environmental
Parameters
|
|
|
Min Operating
Temperature
|
32 °F
|
|
Max Operating
Temperature
|
104 °F
|
|
Humidity Range
Operating
|
5 - 95%
|
