N3K-C3524P-10GX Overview
The Cisco N3K-C3524P-10GX further extends the leadership of the Cisco Nexus 3000 Series by including the innovative Cisco® Algorithm Boost (or Algo Boost) technology. Algo Boost technology, built into the switch application-specific integrated circuit (ASIC), allows the Cisco Nexus 3500 platform to achieve exceptional Layer 2 and 3 switching latencies of less than 200 nanoseconds (ns). In addition, Algo Boost offers several innovations in latency, forwarding, and performance visibility capabilities.
N3K-C3524P-10GX Specification
|
Brand
|
Cisco
|
|
Part
number
|
N3K-C3524P-10GX
|
|
Product
Description
|
Nexus 3524x. 24 10G Ports
|
|
Physical
|
● 24
fixed SFP+ ports (1 or 10 Gbps); expandable to 48 ports
|
|
● Dual
redundant hot-swappable power supplies
|
|
● Four
individual redundant hot-swappable fans
|
|
● One
1-PPS timing port, with the RF1.0/2.3 QuickConnect connector type*
|
|
● One
10/100/1000-Mbps management port
|
|
● One
RS-232 serial console port
|
|
● Two
USB ports
|
|
● Locator
LED
|
|
● Locator
LED button
|
|
Performance
|
● 480-Gbps
switching capacity
|
|
● Forwarding
rate of 360 mpps
|
|
● Line-rate
traffic throughput (both Layer 2 and 3) on all ports
|
|
● Configurable
MTUs of up to 9216 bytes (jumbo frames)
|
|
Typical operating power
|
102W
|
|
Maximum power
|
193W
|
|
Typical heat dissipation
|
348 BTUs
per hr
|
|
Maximum heat dissipation
|
658 BTUs
per hr
|
|
Weight
|
7.9 kg
|
|
Dimension
|
4.36 x
43.9 x 46.7 cm
|
|
Warranty
|
One year
|
|
Lead
time
|
2-3 business days
|
|
Shipment
|
DHL, Fedex, Aramex, EMS or per
request
|
