N9K-C9372PX Nexus 9300 with 48p 10G SFP+ and 6p 40G QSFP+

The Cisco Nexus 9372PX Switch provides a line-rate layer 2 and layer 3 feature set in a compact form factor. It offers a flexible switching platform for both 3-tier and spine-leaf architectures as a leaf node. With the option to operate in Cisco NX-OS or Application Centric Infrastructure (ACI) mode, it can be deployed in small business, enterprise, and service provider architectures.



N9K-C9372PX Overview


 The N9K-C9372PX is a 1RU switch that supports 1.44 Tbps of bandwidth and over 1150 mpps across 48 fixed 10-Gbps SFP+ ports and 6 fixed 40-Gbps QSFP+ ports.


N9K-C9372PX Specification


Brand Cisco
Part number N9K-C9372PX
Product Description Nexus 9300 with 48p 10G SFP+ and 6p 40G QSFP+
Ports 48 fixed 1/10GBASE-T and 6 QSFP+ ports
Form factor 1 RU
Throughput (Tbps) 1.44
Supported speeds 1/10 Gigabit Ethernet speeds
40 Gigabit Ethernet uplink port 6 fixed QSFP+ ports
Advanced QSFP+ optics enable connectivity using existing 10 Gigabit Ethernet fiber.
The switch offers 25 MB of additional packet buffer space shared with all ports for more resilient operations
Typical power(AC & DC) 210W
Maximum power(AC & DC) 537W
Maximum number of longest prefix match (LPM) routes 128000
CPU, SSD, and memory Dual-core 2.5-GHz x86 CPUs with 64-GB SSD drive and 16 GB of memory provide enhanced network performance.
Buffer (MB) 37
Operating System NX-OS, ACI
Fans 4
Physical (H x W x D) 4.4 x 43.9 x 57.1 cm
Acoustics 48.5 dBA at 40% fan speed, 64.9 dBA at 70% fan speed, and 77.8 dB at 100% fan speed
Weight(without power supplies or fans) 10.1 kg
Warranty One year
Lead time 2-3 business days
Shipment DHL, Fedex, Aramex, EMS or per request
