NCM Powder Lithium Battery Cathode Material Lithium Nickel Manganese Cobalt Oxide
Nickel Manganese Cobalt Oxide NMC=1:1:1 Powder
|
Product Name:
|
LiNiMnCoO2
|
Type:
|
TMAX-NMC-111
|
|
SPECIFICATIONS
|
|
Item
|
Standard
|
Test result
|
The analytical methods and instruments
|
|
Element content (wt%)
|
|
Ni+Mn+Cu
|
≧58
|
58.79
|
Consult GB/T1287-94.GB/T15899-1995.HG/T2631-2005: Volumetry
|
|
Li
|
7~8
|
7.29
|
Consult
JY/T 015-1996: Inductively coupled plasma atomic emission spectrometry
|
|
Na
|
≦0.03
|
0.0036
|
|
Fe
|
≦0.01
|
0.0032
|
|
Cu
|
≦0.005
|
0.0001
|
|
H2O
|
≦0.05
|
0.01875
|
Consult.GB/T606-2003 C30 Carle Fischer coulometric instrument
|
|
Distribution of grain size(um)
|
|
d10
|
≧5
|
6.66
|
Consult.GB/T19077.1-2008 Mastersizer2000 laser particle analyzer
|
|
d50
|
8~14
|
10.11
|
|
d90
|
≦25
|
20.69
|
|
Electrochemical performance
|
|
First discharge efficiency(%)
|
≧85
|
87
|
Consult GB/T20252-2006 Appendix C
Button half cell 0.2C 4.2v-2.7v
|
|
First discharge capacity(mAh/g)
|
≧153
|
154.1~154.8
|
|
Physical property
|
|
BET (m2/g)
|
0.2~0.5
|
0.33
|
Consult GBT 13390-200Tristar specific surface area
|
|
TD (g/cm3)
|
≧2.3
|
2.5
|
Consult GB/T5162-2006/ISO3953:1993; FZS4-4B Jolt density meter
|
|
PH
|
≦11.5
|
11.18
|
Consult GB/T1717-1986:DELTA320Ph
|
