New 480x480 resolution 2.5 inch ips round lcd display

New 480x480 resolution 2.5 inch ips round lcd display



Facebook Twitter Pinterest LinkedIn 分享

Specification

LCD type 2.5 inch IPS round tft display module
Display type 2.5" round TFT
Driver element a-si TFT Active matrix
Outline Dimension(mm)
69.19(H)*71.74(W)*2.45(T)(Exclude FPC)
A.A.(mm) 62.64（W）*62.64（L）
Driver IC HX8379-C
Resolution(dots)_ 480*RGB*480
Viewing Direction All
Operating temperature(°C) -20-70
Storage temperature(°C) -30-80
Number of Pixel(pixels) 480(H)x 3RGB x 480(V)
Operating Volatge 3.3v
Logic Voltage 1.8v-2.8v
Pixel arrangement RGB Vertical Stripe
Display mode Normally white
Surface treatment Antiglare, Hard-Coating(3H)
IC Package Type COG
Luminance 400 nits
Backlight white LEDs
Display colors 16.7M
Module lifetime(Hours) 50,000-100,000
