North Benz tractor truck/beiben tractor heads/ truck for sale
Tractor Truck
|
Driving type: 6x4 Based on MAN Design platform
|
Cabin
|
BENZ technology cab, single sleeper, Manual Window, with air-conditioning
|
Engine
|
Diesel, 4-stoke Direct injection,6-cylinder in line, radiator, Turbo-charging.
|
Model:
|
WP10.340E32/250
|
European technology WEICHAI
|
| |
MAX Horse power:
|
340HP/250KW
|
| |
Displacement(L):
|
9.726liter
|
| |
Max torque:
|
1600NM@1200~1600
|
| |
Bore/stoke:
|
125mm/155mm
|
| |
Fuel consumption:
|
197g /kwh
|
Gear box
|
|
Applied American technology
|
| |
Model:
|
FAST 12JS160TA
|
| |
Speed:
|
12speed,2reverse Max torque:1600NM
|
Axle(front/rear)
|
Front axle
|
Benz technology 6.5ton front axle
|
Tandem
|
13TON Benz strengthened axle (punching-welding axle housing)
|
(Driving axle)
|
double reduction driving axle, inter-wheel differential lock
|
Clutch
|
D430 diaphragm type
|
Brake
|
Service brake: Double circuit pneumatic brake
|
| |
Parking brake: Spring-Power drum brake
|
Steering
|
ZF technology, driver sit at the left hand side
|
Electric Equipment
|
| |
Operating voltage:
|
24Vnegative grounded
|
| |
Starter:
|
24V,5.4KW
|
| |
Alternator
|
28V,758W
|
| |
Battery voltage
|
12V/135Ah,cigar lighter
|
Frame
|
300mmx80mmx 8mm (inner: 275mm*70mm*5 mm )
|
Tyre
|
10+1 spare tyre with wheel
|
| |
295/80R22.5 Rim:8.5-20
|
Suspension system: Leaf spring type
|
| |
Front/Rear
|
9/13
|
Overall dimension(mm): 6800x2500x3180(Length x width x height)
|
Wheelbase
|
3200+1350mm
|
Track:
|
|
| |
Front/Rear
|
2045/1800/1838
|
| |
Approach/Departure angle
|
16/60
|
| |
Front /Rear overhang
|
1410/840
|
| |
Max speed
|
110km/h
|
Kerb weight:
|
8450kg
|
Diesel tank
|
300L
|
