North benz 8*4 drive 12 wheeler dump trucks

North benz 8*4 drive 12 wheeler dump trucks , best quality china 50 T heavy duty dump truck supplier for congo country.
Benz unique axle technique
High EFFICIENCY



North benz 8*4 drive 12 wheeler dump trucks



We can supply an unlimited number of different beiben 8*4,6*4 tipper trucks to any country in the world

Beiben military Strong chassis with proven technology make these the work horse of your fleet. With low cost and high profitability, these are the beiben tipper trucks that constructors use.

Many options available:

  • 6×4, 6×6, 8×4
  • front or mid body tipping system
  • LHD or RDH
  • strengthened chassis
  • chose your body type and size; 10 m2, 15 m2, 20 m2
  • With or without backdoor – depending on your demands
  • with different cab types available
  • HP ranges from 280 – 480 HP, with gear boxes to match the power requirements

BEIBEN 8X4 TIPPER Truck

Model

3134KY

Driving type

LHD (Right Hand Drive is optional

Driver's cab

Long cabin, single sleeper

Engine

Maker: WEICHAI

Diesel 4 stroke direct injection diesel engine, 6 cylinder in-line with water cooling, turbo-charging & intercooling

Engine model: WP10 series

EURO II/EUROIII emission standard

Maximum output: 336HP/340 @2200 rpm

Number of cylinder:6

Displacement: 9.726L

Clutch

430mm, hydraulically operating with air assistance

Transmission

FULLER Brand transmission.

Front Axle

Benz front axle 6.5 tons

Rear Axle

Benz 13T double reduction drive axle

Steering

TAS85

Option: ZF8098, hydraulic steering with power assistance

Wheel & Types

Tyres: 12.00R20

Optional: 12R22.5

Radial tire and tubeless tire is optional

Electrics

Operating voltage: 24V, negative grounded

Dimensions in mm

Wheel base:                           1500+3550+1450

Overall size:                       9900×2500×3480

Weight in kg

Kerb weight                             14765

Permissible trailing capacity               40000

Performance

Maximum driving speed(km/h)             85

Body mm

7200x2300x1500 Floor 8 side&back4, front tipping type

The manufacture reserves the right of technical alteration/change for better improvement prior notice
