North Benz /Beiben self loading concrete mixer truck
We are the beiben mixer truck workshop for beiben 8 CBM,9 CBM,10 CBM, self loading concrete mixer truck manufacturer in china. Also supply the super quality beiben 2534,2538 self loading concrete mixer trucks.
NORTH BENZ 6X4 CONCRETE MIXER Truck
|
Model
|
ND5257GJBZ |
Driving type
|
LHD (Right Hand Drive is optional)
|
Driver's cab
|
Long cabin, single sleeper
|
Engine
|
Maker: WEICHAI
|
Diesel 4 stroke direct injection diesel engine, 6 cylinder in-line with water cooling, turbo-charging & inter-cooling
|
Engine model: WP10.380E32
EUROIII emission standard
|
Maximum output: 380HP@2200 rpm
|
Number of cylinder:6
|
Displacement: 9.726L
|
Clutch
|
430mm, hydraulically operating with air assistance
|
Transmission
|
FULLER Brand transmission.
|
Front Axle
|
Using Mercedes Benz technology front axle 7.5 tons
|
Rear Axle
|
Using Mercedes Benz technology 13T double reduction drive axle
|
Steering
|
TAS85
|
Option: ZF8098, hydraulic steering with power assistance
|
Wheel & Types
|
Tyres: 12.00R20
|
Optional: 12R22.5,12R20
|
Radial tire and tubeless tire is optional
|
Electrics
|
Operating voltage: 24V, negative grounded
|
Dimensions in mm
|
Wheel base: 3800+1450
|
Overall size: 8715×2495×4000
|
Weight in kg
|
Kerb weight 8700
|
Permissible trailing capacity 25000
|
Performance
|
Maximum driving speed(km/h) 85
|
Body mm
|
9CBM Mixer body
|
The manufacture reserves the right of technical alteration/change for better improvement prior notice
|
