We have another product、brand,such as :
ESA-LYZ1A13-21
ESA-LYZ1AF1-11
ESA-Y2005A23-21.1
ESA-Y2005A23-31
ESA-Y2020A1S-11
ESA-Y2020A25-21.1
ESA-Y2020GF1-11
ESA-Y2020T25-31
ESA-Y2020TF8-21
ESA-Y3040A23-21
ESA-Y4080A23-21
How to check insulation resistance of the Motor windings:
Check insulation resistance of the Motor windings with the pins of connector on the side of the slider using a tester. (Apply 500V. Resistance shall be 10 Mor over.)
Check the insulation resistance between the pin of respective phases (A, B and C) and FG.
How to measure resistance of the Motor windings
The resistance of the Motor windings shall be checked on the pins of connector on the side of the slider using a tester.
