Dimensions :
|
DIMENSIONS |
||||||
|
TARE WEIGHT |
9000KG |
VOLUME |
40m³ |
|||
|
overall length |
|
11980mm |
overallwidth |
2500mm |
overall height |
3800mm |
Specification :
|
specification |
|
|
tank body |
q235/5mm steel |
|
end plate |
q235a/6mm
steel sheet |
|
axle |
number 3
brand optional capacity
13t |
|
suspension |
mechanical
suspension or Air suspension |
|
leaf spring |
leaf spring or
Air bag |
|
manhole cover |
500mm manhole
cover .2sets with 2breather valve |
|
tire |
11.00r20，12.00r20，11r22.5，315/80r22.5 tire optional |
|
wheel rim |
8.5-20,8.25-20,9.0-22.5,steel
wheel rim optional upon choice |
|
discharge valve |
2-4 set∮100mm discharge valves |
|
ischargepipe |
4’'rubber hose，2pcs，6m long |
|
king pin |
2''/3.5''bolt-in
king pin |
|
landinggear |
jostbrandtwo-speed， manualoperating，heavy duty
landing gear |
|
bottom valve |
1-2 sets of
bottom valve |
|
qutside sheet |
1.52mm steel
sheet |
|
compartment |
optional upon
choice |
|
braking system |
wabco re6 reay
valve：t30/30spring brake chamber：40l air tanks |
|
painting |
complete chassis
sand blasting to clean rust，1cpat of
anticorrosive prime， 2coats of final
|
|
accessories |
one standard
tool box |
|
main beams |
opting for high
tensile steel q345b welded by automatic submerged-arc process |
