Omron CJ1W-DA021 Analog output unit new and Fast Shipping

Omron CJ1W-DA021 Analog output unit Good Quality/ In stock







Omron CJ1W-DA021 Analog output unit Fast ship/ Brand new



Manufacturer : OMRON

Product No. : CJ1W-DA021

Product Type : Analog Output Unit

Isolation : Between I/O and Controller signals: Photocoupler (No isolation between I/O signals.)

External power supply : 24 VDC (inrush current: 20 A max., pulse width: 1 ms min.)

External terminals : 18-point detachable terminal block (M3 screws)

External power supply : 140 mA max.

Power consumption : 5 VDC, 120 mA max.

Number of analog outputs : 2

Output signal range : 1 to 5 V/4 to 20 mA, 0 to 5 V, 0 to 10 V, -10 to 10 V

Output impedance: 0.5 O max. (for voltage output)<

Max. output current (for 1 point): 12 mA (for voltage output)

Maximum permissible load resistance: 600 O (current output)

Resolution: 4,000

Set data: 16-bit binary data

Accuracy : 25°C Voltage output: ±0.3% of F.S., Current output: ±0.5% of F.S.

Accuracy : 0°C to 55°C Voltage output: ±0.5% of F.S., Current output: ±0.8% of F.S

D/A conversion period : 1.0 ms per point

Output functions: Output hold function

Outputs the specified output status (CLR, HOLD, or MAX) under any of the following circumstances.

Dimensions (W × H × D) : 3.1 × 9 × 6.5 cm

Shipping Weight : 2 Kg



Specification:

Brand: Omron

Product Origin: JAPAN

Warranty: 1 Year

Payment: T/T, Western Union

Condition: New with original package

Lead Time: In stock

Model: CJ1W-DA021
