| Rated power supply voltage |
100/110/120 VAC 50/60 Hz |
| Allowable voltage variable range |
85 to 110% of the power supply voltage |
| Power consumption |
Approx. 0.23 VA (at 120 VAC) |
| Approx. 0.22 W (at 120 VAC) |
| Operation start voltage |
30% max. of rated supply voltage |
| Number of time ranges |
4 |
| Operation mode |
Power OFF-delay |
| Control output (Type) |
Time-limit: DPDT |
| Control output (Contact output) |
Minimum applicable load: 10 mA at 5 VDC (failure level: P Reference value) |
| Operating resetting |
Instantaneous operation/Time-limit reset |
| Ambient temperature range |
Operating: -10 to 55 β (with no icing) |
| Storage: -25 to 65 β (with no icing) |
| Ambient humidity range |
Operating: 35 to 85 % |
| Accuracy of operating time |
±0.2% FS max. |
| Setting error |
±5% FS ±50 ms max. |
| Influence of voltage |
±0.2% FS max. |
| Influence of temperature |
±1% FS max. |
| Insulation resistance |
100 MΩ min. (at 500 VDC) |
| Dielectric strength |
Between current carrying metal parts and non-current carrying metal parts: 2,000 VAC 50/60 Hz 1 min |
| Between control output terminals and operating circuit: 2,000 VAC 50/60 Hz 1 min |
| Between contacts of different polarity: 2,000 VAC 50/60 Hz 1 min |
| Between non-continuous contacts: 1,000 VAC 50/60 Hz 1 min |
| Impulse withstand voltage |
Between power terminals: 5 kV |
| Between current carrying terminals and exposed non-current carrying metal parts: 5 kV |
| Noise immunity |
±1.5 kV (between power terminals) and ±600 V (between input terminals), square-wave noise by noise simulator (pulse width: 100 ns/1 µs, 1-ns rise) |
| Static immunity |
Mulfunction: 8 kV, Destruction: 15 kV |
| Vibration resistance |
Destruction: 10 to 55 Hz, 0.75 mm single amplitude each in 3 directions for 2 h |
| Malfunction: 10 to 55 Hz, 0.5 mm single amplitude each in 3 directions for 10 min |
| Shock resistance |
Destruction: 980 m/s2, 3 times each in 6 directions |
| Malfunction: 98 m/s2, 3 times each in 6 directions |
| Life expectancy (relay output) |
Electrical: 100,000 operations min. (5 A at 250 VAC, resistive load at 1200 operations/h) |
| Mechanical: 10 million operations min. (under no load at 1,200 operations/h) |
| Degree of protection |
IP40 (panel surface) |
| Connecting method |
8-pin round socket |
| Weight |
Approx. 120 g |
| Applicable socket |
P2CF-08/ P2CF-08-E/ PF085A/ P3G-08/ PL08/ PL08-Q/ PLE08-0 |
