Factory Supply optical fiber ,All Kinds Of Electronic Products

10G XENPAK CWDM Transceiver

ETU-Link 10Gb/s XENPAK transceiver module EXPCxxX-4SCD40 is a hot pluggable in the Z-direction module that is usable in typical router line card applications, Storage, IP network and LAN and compliant to XENPAK MSA. The EXPCxxX-4SCD40 is a fully integrated 10.3Gbit/s optical transceiver module that consists of a 10.3Gbit/s optical transmitter and receiver, XAUI interface, Mux and De-mux with clock and data recovery (CDR).This version of ETU-LINK Inc. transceiver line uses an cooled CWDM EML Laser Diode to achieve 40km over standard single mode fiber as 10GBASE-ER of the IEEE 802.3ae.

1.25G SFP SC EPON OLT PX20+ Transceiver

Description: EPON OLT PX20+, which is a single-fiber bidirectional optical module with a data rate of 1.25g operation and a center wavelength of 1490nm and 1310nm SC interface with a transmission distance of 20KM.

GPON OLT Class C++ SFP Transceiver

GPON OLT Class C++, a single-fiber bidirectional optical module with a data rate of 1.25g operation and a center wavelength of 1490nm and 1310nm SC interface with a transmission distance of 20KM.

1.25G SFP SC EPON OLT PX20++ Transceiver

Description: EPON OLT PX20++, which is a single-fiber bidirectional optical module with a data rate of 1.25g operation and a center wavelength of 1490nm and 1310nm SC interface with a transmission distance of 20KM.

GPON OLT Class B+ SFP Transceiver

GPON OLT Class B+, a single-fiber bidirectional optical module with a data rate of 1.25g operation and a center wavelength of 1490nm and 1310nm SC interface with a transmission distance of 20KM.

GPON OLT Class C+ SFP Transceiver

GPON OLT Class C+, a single-fiber bidirectional optical module with a data rate of 1.25g operation and a center wavelength of 1490nm and 1310nm SC interface with a transmission distance of 20KM.

1.25G SFP SC EPON OLT PX20+++ Transceiver

Description: EPON OLT PX20+++, which is a single-fiber bidirectional optical module with a data rate of 1.25g operation and a center wavelength of 1490nm and 1310nm SC interface with a transmission distance of 20KM.

10G SFP+ SC EPON ONU Transceiver

EXEP2592-3SCD20 is a transceiver for the optical network unit (ONU) of 10GEPON with 10.3125Gbps in downstreamEXEP2592-3SCD20 is a transceiver for the optical network unit (ONU) of 10GEPON with 10.3125Gbps in downstream and 10.3125Gbps in upstream. and 10.3125Gbps in upstream.

14.025Gbps SFP+ MM 850nm 100M DDM

Description: The ETU-Link SFP+(Small Form-Factor Pluggable) tranceiver, up to 14Gb/s, Distance up to 100M.

14.025G SFP+ BIDI TX1270/RX1330nm 10km DDM

Description: The ETU-Link SFP+(Small Form-Factor Pluggable) tranceiver, up to 14Gb/s, Distance up to 10KM.

14.025G SFP+ BIDI TX1330/RX1270nm 10km DDM

Description: The ETU-Link SFP+(Small Form-Factor Pluggable) tranceiver, up to 14Gb/s, Distance up to 10KM.

8G SFP+ 300M Transceiver

This 850 nm VCSEL 8.5Gigabit SFP+ transceiver is designed to transmit and receive optical data over 50/125 μm or 62.5/125 μm multimode optical fiber.

8G 1310nm 2KM SFP+ Optical Transceiver

ETU-Link’s ES3185-3LCD2 SFP+ transceivers are designed for use in Fibre Channel links up to1.4 km at 8.5Gb/s data rate.

8.5G 1310nm 10KM SFP+ Optical Transceiver

ETU-Link’s ES3185-3LCD10 SFP+ transceivers are designed for use in Fibre Channel links up to1.4 km at 8.5Gb/s data rate.

10M 1X9 SC Bi-Directional Transceiver, 20KM

Description: 1X9 SC Bi-Directional Transceiver is applied in SONET/SDH/PDH Equipment Interconnect.

84M 1X9 SC Bi-Directional Transceiver, 20KM

Description: 84M 1X9 SC Bi-Directional Transceiver is applied in SONET/SDH/PDH Equipment Interconnect.

155M 1X9 SC Bi-Directional 20KM Transceiver

Description: 155M 1X9 SC Bi-Directional 20KM Transceiver 84M 1X9 SC Bi-Directional Transceiver is applied in SONET/SDH/PDH Equipment Interconnect.

0-10M 1310nm SM TTL DX 1x9 Transceiver 20KM

Description: 0-10M 1310nm SM TTL DX 1x9 Transceiver is applied in SONET/SDH/PDH Equipment Interconnect.

0-84M 1310nm Single-mode 1x9 TTL Duplex Transceiver 20KM

Description: 0-84M 1310nm Single-mode 1x9 TTL Duplex Transceiver is applied in SONET/SDH/PDH Equipment Interconnect.

0-100M 1310nm Single-mode 1x9 TTL Duplex Transceiver 20KM

Description: 0-100M 1310nm Single-mode 1x9 TTL Duplex Transceiverr is applied in SONET/SDH/PDH Equipment Interconnect.

155M 1310nm Single-mode 1x9 20km Duplex Transceiver

Description: 155M 1X9 SC Duplex 20KM Transceiver is applied in SONET/SDH/PDH Equipment Interconnect.

6G SFP+ LR 1310nm 10KM Transceiver

Description: The ETU-Link SFP+(Small Form-Factor Pluggable) tranceiver, up to 6Gb/s, Distance up to 10km.

10/100/1000BASE-T SFP Copper RJ45 100m Module

Description: The ETU-Link Copper SFP compliant with 1000BASE-T and connects a SFP port to Category 5 wiring using a standard RJ-45 interface. The maximum Category 5 wiring distance is 328 feet (100 meters).

1000BASE-T Copper SFP RJ45 100M Transceiver

Description: The ETU-Link Copper SFP compliant with 1000BASE-T and connects a SFP port to Category 5 wiring using a standard RJ-45 interface. The maximum Category 5 wiring distance is 328 feet (100 meters).

10/100BASE-T Copper SFP Transceiver

Description: The ETU-Link Copper SFP compliant with 1000BASE-T and connects a SFP port to Category 5 wiring using a standard RJ-45 interface. The maximum Category 5 wiring distance is 328 feet (100 meters).
