Product Details:
- Voltage requirement: 5 V ± 5%
- Current consumption: 220 mA (typical use)
- Light source: 660 nm red LED
- Photo sensor: CCD linear sensor
- Scan rate: 700 scans/sec
- Decode rate: 700 decodes/sec
- Reading pitch angle: -6 to 0°, 0 to 6°
- Reading skew angle: I-type: -30 to -10°, +10 to +30°
- Reading tilt angle: -10 to 0°, 0 to +10°
- Focal plane: 35 mm / 1.38 in
- Curvature: I-type: R>15 mm (EAN8), R>20 mm (EAN13)
- Reading width: 80 mm / 3.15 in
- Min. resolution at PCS 0.9: 0.2 mm / 0.15 mm at 60 mm reading length
- Min. PCS value: 0.45
- Supported 1D barcode Symbologies: JAN/UPC/EAN (WPC) incl. add on, (These symbologies are also supported for barcode stitching) Codabar, Code 39, Code 93, Code 128, EAN13, IATA, Industrial 2of5, Interleaved 2of5, MSI/Plessey
- Trigger mode: external hardware trigger, serial software trigger
- Configuration: parameters can be set by RS 232 or menu book
- Interface: RS232
Environmental specifications
- Temperature in operation: 0 to 40 ºC / 32 to 104 ºF
- Temperature in storage: -10 to 60 ºC / 14 to 140 ºF
- Humidity in operation: 20 - 80 % (non-condensing)
- Humidity in storage: 20 - 90 % (non-condensing)
- Ambient fluorescent light immunity: I-type: 3,000 lx max.
- Ambient white light immunity: I-type: 10,000 lx max.
- Antistatic electricity: 15 kv (non-destructive)
- Shock packed drop test: 1.5 m / 5 ft drop onto concrete surface
- Shock drop test: 0.6 m / 2 ft drop onto concrete surface
- Shock vibration test: 12 - 100 Hz with 2G for 3 hours
