Our LED stage screen performance of the scene image, abstract picture, can ourphp a dream effect.
Equipped with professional audio and video processing system, support for a variety of signal processing, from the signal processing to ensure the quality, making it possible to play a high fidelity image signal.
, with dual hot backup line function, two computers and the control of a screen, when when there is a problem with a computer, and another computer automatically succeed to ensure display normal work.
A, the indoor stage HD LED full color display is mainly used in high-grade entertainment disco, large-scale song and dance show, fashion conference, television, large conference room, auditorium of the center of the stage the main display screen and scenic view screen.
ourphpacteristic:
1 high density, high definition display;
2 with photosensitive control system, according to the change of indoor and outdoor light automatically adjust the brightness of the display, both energy-saving and environmental protection, greatly reducing the cost of your running, but also make the audience more easily accept;
3 product launch has a set of low power solution, can make the screen running more than the original energy saving 1/3, further greatly reducing the cost of your running;
. with high refresh rate and high gray, so more realistic, meet business demands of high visual quality and meet the needs of different occasions shooting LED display screen, effective way to avoid the flicker phenomenon when shooting;
5 with brightness, color point by point correction function, the LED display screen is more rich, meet the requirements of high quality of commercial use, and can be used for different batches of the screen body;
6 equipped with professional audio and video processing system, support for a variety of signal processing, from the signal processing to ensure the quality, making it possible to play a high fidelity image signal;
7. With dual hot backup line function, two computers and the control of a screen, when when there is a problem with a computer, and another computer automatically succeed to ensure display normal work;
8 with light, slim, fast installation design, so that you can complete the installation and removal of the display in a short time;
9 support signal line any direction, meet the different boxes, placed, to ourphp a different effect of the picture;
10 with various specifications of the air box, easy to store and transport, and the LED display has played a very good role in the protection.
SPECS
|
Item
|
Value
|
|
Pixel Pitch(mm)
|
6
|
|
Pixel Density(pixels/㎡)
|
27777
|
|
Pixel Configuration
|
SMD
|
|
Viewing Angle（deg.）
|
160(H)/160(V)
|
|
Brightness(nits)
|
5000
|
|
Gray Level（Bit）
|
12/14/16
|
|
Refresh Rate（Hz）
|
1920/2880/3840
|
|
Panel Size (m)
|
1.92X19.2
|
|
Panel Size（inch）
|
75X75
|
|
Panel Resolution（pixels）
|
320X320
|
|
Panel Material
|
Aluminum & Iron
|
|
Weight（kg/pcs）
|
≤30
|
|
Module Size(W)×(H)(mm)
|
192X192MM
|
|
Module Size(W)×(H)(inch)
|
7X7
|
|
Module Resolution(pixels)
|
32X32
|
|
Protection Grade
|
IP65/IP54
|
|
Serviceability
|
Front/Rear
|
|
Voltage(V)
|
AC 100~AC 240
|
|
*Avg. Power Consumption （W/㎡）
|
145(AC)
|
|
*Max. Power Consumption（W/㎡）
|
580(AC)
|
|
Operating Temp/Humidity(℃/%RH)
|
-20~50/10~90
|
|
Storage Temp/Humidity(℃/%RH)
|
-40~60/0~90
|
|
Lifetime(Normal Temp)hours
|
100000
|
|
Compliant Standard
|
TUV-CE,FCC
|
|
*Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to LianTronics
|
