Outdoor IP Rated COOLIE 545 54X3W STAGE PAR

Features

• Light source: 54 x 3W RGBW LED
• Beam Angle: 19°
• Lux@5m: 3500lux
• With powerful beam and wash effects
• Excellent color mixing effect
• Preset program in stand-alone mode
• 4 dimming curves
• 0~100% smooth dimming
• Outstanding strobe effect with variable speed
• Flicker free management
• Dust-proof and oil-proof design
• Protection Rating: IP66
• Flicker free management

  Light source

  • Light source: 54 x 3W RGBW LED
  • LED life expectancy: 60000 hours



  Optical system

  • Advanced optical system to ensure clear and large-range beam & wash effect
  • Beam Angle: 19°
  • Lux@5m: 3700lux



  Control and Program

  • 4-buttons
  • Display: LED display
  • Protocols: DMX, Master/Slav
  • DMX Protocol modes: 3
  • Control channels: 4,5,7
  • Upgrade the firmware via DMX link



  Electrical and Connectors

  • Power supply with electronic auto-ranging
  • Input voltage range: AC 100-240 V, 50/60 Hz
  • Power consumption: 173 W
  • Power cord out
  • Data in/out: 3-pin XLR socket



  Fixture Specification

  • Height: 350 mm (13.7")
  • Width: 302 mm (11.8")
  • Depth: 230 mm (9.0")
  • Weight: 9 kg (19.8 lbs)



  Work Environment

  • Maximum ambient temperature: 40°C
  • Maximum surface temperature: 65°C
  • Minimum operating temperature: 0°C
  • Protection Rating: IP66



  Installation

  • Horizontally or vertically mounting are available
  • Operating position is universal
  • The feet support with 3 locking points
  • Safety cable attachment point



  Included Items

  • User Manual
  • Power Cable
