1. MBI5024 drive IC;
2. All EPISTAR LED;
3. Not less than 6,500 nits;
4. 150 mm thickness of cabinet;
5. Plywood case packed.
Application:
Outdoor LED billboard is used for highway advertising.
Feature & Function
Items P6
Classification of items Full color
Application environment Outdoor
Pixel pitch 6mm
LED lamps SMD3535
Optimum viewing distance 5m
Optimum viewing angle H:140°V:140°
Module size 192X96mm
Module resolution 32x16dots
Physical pixel 27777 dots/m2
Pixel constitution 1R1G1B
Cabinet size 1360X600MM
Cabinet material Iron coated epoxy
Cabinet structure outdoor fixed
Typical power consumption 800W/sqm
Driving method 1/8 scan Constant Current
Frame frequency ≥60Hz/s
Refresh Rate ≥400Hz/s
Luminance of White Balance ≥1200 Nits
Operating environment temperature -20°C - +45°C
Working voltage 110-220VAC+-10%
Grey Scale/ Color Displaying colors≥16.7M(Synchronized)
Brightness Adjustment 256 levels of each color
Input singal RF,S-Video,RGB,RGBHV,YUV,YC & Composition,etc
Software LED studio(LINSN)
Control system main controller card (sending card and receiving card)
Average level of no failure time >5000 hours
Life span >100,000 hours
Malfunction Dot Rate <0.0001
Our Service and Mission
CX LED has a perfect service system, including pre-sale service, in-sale service and after-sale service. To provide high quality service for our customers, we train every salesman with necessary product maintenance knowledge and organized a Technology Supporting Department with a group of excellent and professional engineers. Any problem you can contact us at any time you like.
Pre-sale service:
1. Reply enquiries in 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Data sheet and samples offer.
5. Other services, such as special packing design, factory visiting and so on.
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
3. Photos and videos as per customer's requirement.
4. Free spare parts.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.
