P1.25 indoor small pixel pitch led screen wall
It delivers an image which is super subtle and without getting tired after a longtime watchin.
Super High Refresh Rate, High Frame Frequency, No Ghosting & Twisting or Smear.
Front Serviceable Module allows easy Maintenance, Saving Time & Spac.
16 Bit Grey Grade Processing, the color transition will be more natural.
16:9 New Generation Small Pitch Screen
Cabinet size is 16:9 golden ratio.Video pixel to LED pixel achieve full 2K/4K/8K displaying. No gap between unit is a revolution of visual enjoyment.
Parameters:
|
Pixel Structure
|
SMD1010
|
|
LED Model
|
1.25
|
|
Pixel Density（dots/m2）
|
640000
|
|
Module Resolution（W×H）
|
160×135
|
|
Module Size（mm）
|
200（W）×168.75（H）
|
|
Module Maximum Power Consumption（W）
|
25
|
|
Module of Cabinet （W×H）
|
3×2
|
|
Cabinet Resolution（W×H）
|
480×270
|
|
Cabinet Size（mm）
|
600（W）×337.5（H）×80（D）
|
|
Cabinet Area（m2）
|
0.2025
|
|
Cabinet Weight（kg）
|
9.9
|
|
Cabinet Flatness（mm）
|
≤0.2
|
|
Maintain Style
|
Pre maintenance
|
|
Cabinet Flatness(mm)
|
≤0.1mm
|
|
Cabinet Material
|
die-cast aluminum
|
|
singel pix brightness corretion
|
have
|
|
singel pix chroma corretion
|
have
|
|
white balance brightness（nits）
|
200～600Adjustable
|
|
Color Temperature（K）
|
3200～9300Adjustable
|
|
viewing angle (HorizontalVerticla)
|
160/160
|
|
Light Pixel Centerline Spacing Difference
|
<3%
|
|
Brightness/Color Uniformity
|
≥97%
|
|
Contrast Ratio
|
5000:1
|
|
Max Power consumption（W/m2）
|
600
|
|
Avg Power Consumption（W/m2）
|
250
|
|
Power supply requirement
|
AC90～264V，frequency 47～63（Hz）
|
|
Frame Frequency（Hz）
|
50&60
|
|
Driving Mode
|
Constant current drive，1/30 scan
|
|
Grey Scale
|
65536
|
|
Refresh Rate（Hz）
|
Maximum 3840 to 5760
|
|
Color Processing Level
|
16bit
|
|
Video Effect
|
2KHD、4K/8K Ultra Picture
|
|
Working Temperature/Humidity（℃/RH）
|
-20～60 / 10%～85%RH（No moisture condensation）
|
|
Storage Temperature/Humidity（℃/RH）
|
-20～60 / 10%～85%RH（No moisture condensation）
|
|
Certificate Standard
|
UO, EMC, ROHS, CE, CCC，TUV-CE
|
