P2 indoor full color rental led screen(512*512MM)

 high density,high contrast,high brightness,high gray,high refresh.die casting aluminum design,light and thin ,high accuracy. seamless stitching of any size. wide viewing angl

Facebook Twitter Pinterest LinkedIn 分享

P2 indoor full color rental led screen




INDOOR P2 SMD 3IN1 TECHNICAL PARAMETERS

Unit Module

Item Parameter
Model Number cn-P2-32S
Module size 128mm*128mm
Pixel pitch 2mm
Pixels Density 250000pcs/m2
Pixel configuration 1R1G1B
Package mode SMD1515
Pixel resolution 64dots(W)*64dots(H)
Max Power consumpion 48W
Module thickness 17mm
Weight 0.45KG
Drive type Constant drive
Scan mode 1/32scan
Port type HUB75
Brightness of white balance ≥800cd/㎡

bracket

Size 256mm*128mm

LED

Unit Module

Dimension 512mm*512mm
Quanty of Module 16
Power supply 5V/60A*4 pcs
Thermal discharge fan 1pcs
Pixel per cabinet 256*256
Best viewing distance 2M～10M
Best viewing distance 140°(W) 120°(H)
Temperature storage:-35℃～+85℃ working:-20℃～+50℃
Opration humidity 10%-95%
Thickness 85mm

Power

Working voltage AC220V±10%
Average Power consumption 260W/㎡
Max.Power consumption ≤800W/㎡
Current ≤20mA(single LED)

Control system

CPU Pentium4 or above
Operation system WIN98/2000/NT/XP
Control method Synchronization

Main technical

parameter

Driving device Constant currentdriver
Refresh frequency ≥400HZ
Grey scale/colors 256levels of each color(RGB)/16.7M colors
MTBF ≥9000hours
Power switch Automatic switch
Display Mode 800*600/1024*768
