Pixel
|
Dot Pitch
|
5 mm
|
|
Pixel Configure
|
1R1G1B SMD 3IN1
|
|
Pixel Density
|
40,000 Pixel/m²
|
|
LED Lamp
|
LED TYPE
|
SMD 2727
|
|
Chip Brand
|
EPISTAR
|
|
Wavelength & Brightness
|
Red:620-625nm;>270mcdGreen:520-525nm;>550mcd
Blue:470-475nm;>90mcd
|
|
Module
|
Module Resolution
|
64 Pixel * 32 Pixel
|
|
Drive Mode
|
Constant Current Drive
|
|
Scanning Method
|
1/8 Scanning
|
|
Module Dimension
|
320 mm(Width)x160 mm(Height)
|
|
Drive IC
|
MBI5124/MBI 5153 /ICN2038S /ICN2053
|
|
LED & Drive Composition
|
Light-Drive Combo
|
|
Refresh Rate
|
>1920HZ
|
|
Cabinet
|
Cabinet Thickness
|
80 mm
|
|
Cabinet Assembly
|
Connecting Sheet
|
|
Cabinet Color(Front/Back)
|
Customized
|
|
Aviation Plug
|
wp20
|
|
Maintenance Mode
|
Front / Back Maintenance
|
|
Cabinet Material
|
Die Casting Aluminum
|
|
Cabinet Dimension
|
640*640 mm
|
|
Module QTY
|
2(Width)X4(Height)
|
|
Power Supply
|
G-energy /Mean well
|
|
LED Screen
|
Viewing Angle
|
Horizontal : 140 ° Vertical: 140 °
|
|
Brightness
|
5500-6500cd/m²
|
|
Best Viewing Distance
|
5~50m
|
|
LED Life
|
100,000Hours
|
|
Maximum Power
|
800w/m²
|
|
Average Power
|
400w/m²
|
|
Input Voltage
|
220V±10% Or 110V±10%
|
|
Operation Environment
|
Temperature: -20°C~60°C; Humidity: 10%~95%
|
|
Protection Grade
|
IP 65
|
|
LED Screen Weight
|
14 kg/cabinet
|
P5 Outdoor LED Video Wall Signboard Outstanding Features:
1. Customized LED video display panel size and structure, no matter biggest or smallest led screen, we can make custom led screens, also we can provide you led panel technology.
2. Adopted with self developed steel structure and special kits will be kept in good flatness and smoothness, we can meet your needs and give you suitable led video wall panel price.
3. According to environmental change,the brightness can be adjusted automatically for energy saving led digital board.
4. Special PVC kits are adopted to protect from corrosion according to coastal weather which is good for led message signs and led text display.
5. Auto power on/off, work unattended & Electrical surge protection which is suitable for large led panel and led display sign board for outdoor led digital signage.
6. High quality LED chip and high anti-static electricity capacity, led video wall for sale now and we will provide you best led sign board price, we are your stable led display supplier.
7. Large viewing angle and smooth displaying provide excellent visual effect from every angle, whether you need indoor led signs or p10 outdoor led display , we can meet your needs.
8. The integration of lamp and driving IC,together with with the multi-circuit structure,achievs evenly-distributed current, low power consumption and fast heat dissipation.
9. Ultra high brightness, low attenuation, high reliability and weather ability. We are good digital display manufacturers can provide you with best outdoor led wall board display panel price.
10. High contrast ratio. Adopting black lamps can improve the contrast ratio by 50%. If you are led display importers, we can provideo you both outdoor and indoor led panel screen.
11. High refresh rate, high gray scale, ghost-canceling, low power consumption, low EMI, anti-creeping, multi-route redundancy backup-supporting, and dot-by-dot-calibration for led screen commercial and external led display.
