P6.667 outdoor SMD3535 RGB full Color led Display board

Refresh rate: 1920Hz

Brightness: ≥7500 CD/m2

Cabinet Size:960*960mm


  • Warranty TimeGuarantee Period 5 Years
  • CertificationUL CE ROHS FCC EMC ISO TUV ETL SGS SAA BIS SASO UV PVOC KC BQB FCC-ID FDA LVD MON C-TICK
  • Packaging DetailsWooden Box Flight Case Carton Box

P6.667 outdoor SMD3535 RGB full Color led Display board


Solution Features

Led display boardOutdoor Advertising use, applicable to stadium, commercial purpose, bank, stock market, savings,quay, shopping mall, bus station, telecommunication, police, monitor, school,restaurant,hotel, pub, firm, ect.



Technical Features

1.Universal module size: 320*160mm; Screw holes of the modules are at the same size and position


2.Universal module compatible to same cabinets, shorten production lead time. Customers can take the same cabinets when changing different pitch products with the same steel structure.


3.Product is high brightness, high refresh, high IP rating, applicable to outdoor media and advertisement occassions.



Specification:


Pixel Configuration

SMD3535

Pixel Pitchmm

6.67

Pixel Densitydot/m2

27777

Module Pixel Matrix (W×H

48×24

Module Size(mm

320(W×160(H

Module Weight(kg

0.6

Module Power Consumption Max.(W

30

Module/Panel(W×H

3x6

Panel Resolution(W×H

144×144

Panel Size(mm

960(W×960(H×160(D

Panel Weight(kg

35

Maitainence Mode

Rear Maitainence

Panel type

Steel cabinet

Brightness(nits

7000

Color Temperature(K

3200—9300

Viewing AngleHor/Vert°

140/120

Power Consumption Max(W/m2

1000

Power Consumption Avg(W/m2

200-300

Operating Power Source

AC90~264V,Frequency 47-63Hz

Frame Frequency(Hz

50&60

Drice Mode

Constant Driving,1/8S

Gray Scale

65536

Refresh Rate(Hz

1920 to 3840

Gray Scale per Color Level

16bit

Working Temperature/Humidity(℃/RH

-20 – 60  / 10%-85%RH

Storage Temperature/Humidity(℃/RH

-20 – 60  / 10%-85%RH
