P6 full color advertising led screen suppliers

Our product have CCC,CE&Rohs,ISO9000,FC, .Life span:more than 100000h. Excellent after-sales services with free repaire whole life. MOQ: 1sqm p6 led screen(inclued 27pcs modules ,5pcs power supply ,receiving card, led border ,led corner ,flat cables and power lines etc)

Facebook Twitter Pinterest LinkedIn 分享

P6 full color advertising led screen suppliers outdoor led video wall


MOQ: 1sqm p6 led screen(inclued 27pcs modules ,5pcs power supply ,receiving card, led border ,led corner ,flat cables and power lines etc)
Our package type: wooden case suit for fixed installation.
Prompt delivery: 15 working days after get deposit.
Support 1920*1080、1280*720、800*600 HD large screen.
A9 1GHZ CPU, the fastest  CPU in LED controllers.
Support 1080P HD video hardware decoding, excellent video effect.
4GB, can store 4-hours HD video files.
Support import video by U-disk directly, play and plug.

Module Parameter
Size 192mm(H)×192mm(H)
Module Resolution 32(H)×32(V)
Pitch6 mm
Density 27777 pixels/m²
LED Lamps SMD3535
Driver IC Universal chip
Module Refresh 1200hz
Mask Pure Black mask-high contrast screen
Cabinet Parameter
Cabinet Resolution 192(H)×192(W)
Cabinet Size 576mm(H)×576mm(W)
Cabinet Weight 11.88kg
Driver Mode Dynamic 1/32 scan , constant current driving
Cabinet Power ≤300w
Cabinet Thickness ≤75mm+5mm
Electricity Parameter
Optical Ratings
Brightness Of  White Balance ≥1600cd/m²
View Angle 140 degree ( horizontal)  140degree(vertical)
View Distance 3m-30m
Gray Scale 16384
Display Color 3-in-1 RGB
Brightness Adjustment 100 levels
Power Supply
Operation Power AC100-240V 50-60HZ  Switch-able
Maxim Power Consumption 1000 w/m²
Average Power Consumption 600 w/m²
Control System
Correction Scale Level 16bits
Screen Refresh Frequency 360Hz
Gamma Correction -5.0—5.0
Support Input HDMI,DVI,VGA,RJ45,USB,Serial Port
Control Distance Ethernet cable 100m, optical fiber 5km
Support VGA Mode 800×600,1024×768,1280×1024,1600×1200,1920×1080
Color Temperature 5000-9300 adjustable
Brightness Correction dot by dot, module by module, cabinet by cabinet
Reliability
Temperature Storage:-35℃-+80℃  ; Operation :-25℃-+45℃
Humidity Storage:10-70% RH   ; Operation:10--60% RH
Operating Life ≥100,000 hours
MTBF ≥5000 hours
Continuous Working Time ≥48 hours
Protection Level IP25
Out of Control Pixel Rate

0.03%
