1. Brushed aluminum cabinet;
2. 64 × 32 dots LED module;
3. 320 × 160 mm module dimension;
4. 7 cm thickness;
5. Super-thin power source;
6. Not less than 1500 nits.
7，size can be custom made
Detail Description:
1. Light weight: it can be loaded by one person, quick assembling, quick maintain, reduce. carrying, save costs.Each cabinet is composed with 2 by 4 pcs LED modules, with size 640 by 640 mm;
2.Thin cabinet:the thickness isonly10 CM, the space of the screen is small , and the entire screen will be more beautiful.
3. Flat screen: smooth surface error is under 0.2cm, it can remove the mosaic phenomenon .effectively.
The effect of the display will be more clear and exquisite.
4. Quick dismounting: adopt fast locking structure connected, firm, quick, beautiful
5. Low release heat: low noise, low consumption, low cost, excellent thermal design and excellent thermal dispersion.
6. Full compatible: new structure design which can demand the indoor displays’ require.
Application:
Advertising LED display, Stadium perimeter LED display, Mobile LED display for mobile media, shopping mall LED display for logo showing, bank & stock exchange LED display for rates showing, train & bus station
Feature & Function
|
Model : CX-PH5 RGB08A
|
|
|
|
|
|
LED Module model
|
|
color
|
1R1G1B
|
|
LED Type
|
SMD2121
|
|
Module Resolution
|
W 64 x H 32
|
|
Module Size (mm)
|
W 320 x H 160
|
|
Driving Method
|
1/16 scan
|
|
LED display parameter
|
|
voltage
|
220V or 110V ± 10%
|
|
Material
|
indoor Die-cast aluminum waterproof ( IP 20 )
|
|
Cabinet Size （mm)
|
W 640x H 640 MM (25X25 Inch)
|
|
Cabinet Resolution (pixel)
|
W 128 x H 128
|
|
power Consumption Max (w/set）
|
200 Watt
|
|
Brightness ( CD/㎡）
|
≥1500
|
|
Net Weight (kg)
|
12 kg
|
|
Viewing Angle
|
120° / 70°
|
|
Theoretic LED Working Life
|
More than 100000 hours
|
|
control method
|
network port control (USB, wifi, optional)
|
|
display function
|
Date,Text, picture, logo , video.
|
