| Electrical data |
| Purpose of U1 |
Module supply |
| Supply voltage (V) |
24 V |
| Type of supply voltage U1 |
DC |
| Power consumption DC |
1.4 W |
| Potential isolation U1 |
Yes |
| Purpose of UINT1 |
Module supply |
| Source of internal voltage |
Via base unit |
| Voltage type of UINT1 |
DC |
| Fieldbus interface |
| Fieldbus interface |
PROFINET |
| Fieldbus device type |
IO device |
| Selectable transmission rates |
100 MBit/s |
| Connection fieldbus |
2 x RJ45 |
| Galv. isolation fieldbus |
Yes |
| Environmental data |
| Ambient temperature standard |
EN 60068-2-14 |
| Ambient temperature |
0 - 60 °C |
| Storage temperature standard |
EN 60068-2-1/-2 |
| Climatic suitability standard |
EN 60068-2-30 |
| EN 60068-2-78 |
| Condensation permitted? |
Not permitted |
| Perm. operating height ASL |
2000 m |
| EMC to standard ... |
EN 61131-2 |
| Vibration to standard ... |
EN 60068-2-6 |
| Acc. shock to standard1 |
15g |
| Clearance & creepage dist. to |
EN 61131-2 |
| Overvoltage category |
II |
| Pollution degree clear.&creep. |
2 |
| Protection type standard |
EN 60529 |
| Protection type, mounting |
|
| Protection type, housing |
|
| Terminal protection type |
|
| Mechanical data |
| Mounting position |
horizontal on top hat rail |
| DIN-rail dimensions |
35 x 7.5 EN 50022 |
| Housing material lower section |
PC |
| Housing material front plate |
PC |
| Housing material upper part |
PC |
| Connection terminal |
Screw terminal |
| Spring-loaded terminal |
| Flex. cond. c/s AWG info |
24 - 12 AWG |
| Height dimension |
101.4 mm |
| Width dimension |
22.5 mm |
| Depth dimension |
110.4 mm |
| Net weight |
86 g |
| Gross weight |
96 g |
