Product Overview
Specifications: PLC1746-P2 SLC 500 Power Supply, Nominal Input Voltage: 120 or 220V AC; Input Voltage Range: 85-132V AC, 170-265V AC; Max Inrush Current: 20A; User Output Current: 0.2A @ 24V DC; User Output Voltage Range: 18-30V DC; Backplane Output Current: 5A @ 5V DC, 0.96A @ 24V DC; Frequency: 47-63 Hz; Fuse: 3A, 250V; Wiring: maximum two 14 AWG wires per terminal; Location: 1746 chassis side; Dimensions (HxWxD): 140 x 74 x 145 mm (5.5 x 2.9 x 5.7 in); Weight: 1.1 kg (2.5 lb).
Miscellaneous: The terminals on the PLC 1746-P2 Power Supply provide an isolated, nonfused 200 mA, 24V DC power. PLC 1746-P2 power supply must be mounted directly on the left end of the 1746 I/O chassis. The 1746-P2 power supply has selectable 120V or 240V operation mode which can be chosen by setting a jumper, no special wiring is required. All 1746P2 power supplies have a LED that indicates proper supply power.
