Designed for general purpose applications, the PowerFlex 753 AC drive off ers multiple options and features along with the added benefi t of simple integration. The PowerFlex 753 comes standard with built-in I/O making it a cost eff ective solution ideal for OEMs and system integrators looking to reduce engineering costs, deliver machines to market faster and meet enduser demand for more productive and safer machines.
PowerFlex 753 at a glance
Ratings
380…480V:
600V:
690V:
0.75…270 kW / 1.0…400 Hp / 2.1…477 A
1.0…300 Hp / 1.7…289 A
7.5…250 kW / 12…263 A
Motor Control • V/Hz Control
• Sensorless Vector Control
• Vector Control with FORCE Technology (with and without encoder)
• Interior Permanent Magnet with and without encoder
Enclosures • IP00/IP20, NEMA/UL Type Open
• Flange Mount
• IP54/NEMA/UL Type 12
Safety
• Safe Torque-Off PLe/SIL3 Cat. 3
• Safe Speed Monitor PLe/SIL3 Cat. 4
Additional Features
• DeviceLogix
• Predictive Diagnostics
• Adjustable Voltage Control
• Three option slots for I/O, feedback, safety, auxiliary control power, communications
• Indexing
• Pump Jack and Pump Off for oil well applications
• Pjump and Traverse for Fibers application
• Conformal Coating
• DC Link Choke
• Automatic Device Confi guration (1)
Certifi cations • ATEX Certifi ed with appropriate options
• c-UL-us
• CE
• EAC
• EPRI/SEMI F47
• FS ISO/EN13849-1 with Safe Torque-Off option
• KCC
• Marine (ABS, Lloyd’s Register, and RINA)
• RCM
• RoHS compliant materials
• TÜV (2)
Options See pages 90…109
(1) Requires Dual-port EtherNet/IP Option Module (Cat. No. 20-750-ENETR),fi rmware V7, Studio 5000 Logix Designer, and Drive Add-On Profi les Version 4.04 or higher.
(2) Certifi cation applies to 20-750-S and 20-750-S1 Safety Options when installed in drive.
