Main technical parameters

TMAX-AP001

TMAX-AP002

Size(L*W*H)

700*2250*1860mm

1000*3800*1900mm

Weight

870kg

1200kg

Applicable aluminum-plastic film area

Max:380*200mm

Max:600*350mm

Thickness of aluminum film

0.11-0.2mm

0.11-0.2mm

Depth of stamping pit

Single pit<6mm

Single pit<6mm

Speed of stamping shell

200-450pcs/H

100-240pcs/H

Cylinder pressure

10T

30T

Stamping mode

Air cylinder

Servo

Power source

AC220V 0.5KW

AC220V 3.8KW

Gas supply

0.6-0.7Mpa 40L/S

0.6-0.7Mpa 40L/S
