Power Backup System, Modular Online UPS for Industrial CMS-90/15UH5

Power range: 15 to 90 kVA
Spec: 120/208VAC, 127/220VAC, 50/60Hz, 3-phase
Tech: high frequency modular UPS, rational redundancy.
Modular, hot-swappable, field-replaceable STS, monitor, UPS module.
Scalable from 15KVA to 90KVA. Parallel-capable up to 360KVA.

Facebook Twitter Pinterest LinkedIn 分享
Overview
CMS UPS units are non-isolated, industrial level, green UPS, adopting advanced modular power protection concept. It delivers the best combination of rectifier, filter, charger, inverter and intelligent power protection. Applying innovated current sharing rectifier control, master-slave synchronization in sequence control, multi-level decentralized control and 3-level sine wave modulation technology, it features great efficiency, flexibility and reliability.
Feature
    1.Rational redundant structure
    UPS module: 15 kVA; UPS System: 90 kVA
    2.Great performance index: input PF ≥ 0.99, output PF:0.9: overall efficiency ≥ 93%
    3.N+X module-level redundancy UPS System
    4.Multi-level decentralized control technology and Master-slave synchronization in sequence control which result in eliminate system failure bottleneck
    5.Each module automatically even shares the input and output current, all UPS modules share batteries
    6.Battery management:
    Battery discharge management, auto-transfer between floating and even charging, temperature compensation
    7.Space-saving high density design, Rack-based for agility and aesthetics
    8.Monitor Function
    C/S-Oriented Architecture SICON Software which is available to monitor multiple UPS up to 600 sets;
    9.Standard configuration Manual maintenance bypass, SPD (Class C), RS232, RS485/RS422 Communication ports,     Remote monitor software, day contacts
    10.Optional configuration
    Input/output Transformer, Battery Bank, IPDS (Intelligent Power Distribution System)
Application
    IDC date center, government, telecom, bank, security, transportation, broadcast&TV network, HealthCare, Communication, E-business, Finance, etc.
