Power Star Beiben 6x4 tipper truck With Low Price , we produce and supply power star 6*4 dump trucks, power star left hand drive dump truck and power star right hand drive dump truck.
1.shortest delivery time
2.more competitive price,
3.reliable and high efficient performance
4.good after-sales service
Product Description
SPECIFICATIONS FOR beiben DUMP TRUCK
|
Vehicle Specifications
|
Model
|
ND32601B38J
|
Traction 4X2,6X4,8X4
|
6X4
|
Power
|
340HP
|
Weight Parameter
|
Complete Vehicle Kerb Mass(kg)
|
12310
|
Maximum authorized total mass (kg)
|
26000
|
Dimension Parameter
|
External Dimensions(mm)
|
Length (mm)
|
7169/7680
|
Width(mm)
|
2495/2500
|
Height(mm)
|
3180/3430
|
wheelbase(mm)
|
3800+1450
|
Internal cargo Sizes
|
Length (mm)
|
5200
|
Width (mm)
|
2300
|
Height (mm)
|
1200
|
Performance Parameter
|
Maximum Speed(km/h)
|
75
|
Maximum Grade ability(%)
|
35
|
Turning diameter(m)
|
16
|
Recommended Configuration
|
Engine
|
Engine Type
|
WD615.34
|
Rated power(kW)/Rev(r/min)
|
250/2200
|
Horse power
|
340HP
|
Torque(N*m)/Rev(r/min)
|
1350/1500
|
Transmission
|
9JS150A
|
Clutch(mm)
|
430
|
Gearbox
|
9 forward gears/ 2 reverse gears
|
Axle
|
Front Axle
|
BENZ-7.5
|
Rear Axle
|
BENZ-13
|
Axle load-bearing
|
Front axle
|
7500
|
|
Rear axle
|
13000
|
Fuel Tank(L)
|
400
|
Track(mm)
|
1995/1800/1800
|
Front overhang/rear overhang(mm)
|
1320/1700
|
Type
|
12.00R20
|
Cabin
|
Sleeper
|
one
|
OTHER
|
Engine horse power
|
290hp,330hp,340hp and 360hp,380hp is optional
|
Tyre
|
nylon,radial and tubeless is optional
|
ABS
|
optional
|
COLOR
|
optional
|
