Specification
LIGHT SOURCE
Lamp: 24pcs*10W 4in1/5in1/6in1 LED
Lifespan: 50,000H
OPTICS
Lens size: 29mm
Beam angle: 25 °/45 °/60 °
COLORS
4in1/5in1/6in1
LED linear color
mixing
FEATURES
Dimmer: 0-100% linear electronic dimmer
Dimmer mode: 4 dimmer modes
Strobe: 1-20Hz or random
Protocol RDM compatible
LED controlled in indepent groups
Perfect pulse and rainbow effect
Smooth color mixing
DISPLAY
Green backgroud LCD screen
15 second standby auto lock
SOFTWARE
Control mode: DMX512, master-slave,
auto-run, sound activate
Channel: 9CH
OTHER SPEC
Constant current driver
32bit MCU with ARM cortex
Working temperature monitoring
Over-temperature protection
Intelligent cooling system
LED display menu on/off
Built-in auto and fade program
Body Material: Aluminum Die-casting
POWER
Voltage: AC100-240V, 50/60Hz
Power Consumption: 200W@220V
DIMENSIONS AND WEIGHT
Fixture dimension: 22x22x23cm
Packing dimension:
52x52x25cm(4 in 1 Carton)
72x55x35cm(6 in 1 flightcase)
Net Weight: 3kg
Gross Weight:
15kg(4 in 1 Carton)
44kg(6 in 1 flightcase)
