Specifications
| Part / Model Number |
GP2600-TC41-24V |
| Series |
GP-2600 Series |
| Manufacturer |
Pro-face/Xycom |
| Display Color |
256 colors (without blink)/ 64 colors (with blink) |
| Display Type |
TFT Type Color LCD |
| Resolution |
800 x 600 pixels |
| Screen Size |
W246mm(9.69in) x H184.5mm(7.26in) |
| Power Consumption |
50W or Less |
| Ambient Operating Temperature |
0°C to 50°C |
| Electrostatic Discharge Immunity |
6kV |
Product Description
Introduction
The Pro-face GP2600-TC41-24V is a 12" programmable display designed for industrial applications. This unit is part of the GP 2000 series and offers advanced capabilities when compared to other HMIs, such as industrial network connectivity. The unit has 4 MB of Application memory (Flash EPROM) supported by an additional 256 KB of backup memory on the lithium battery. The GP2600-TC41-24V supports several language character fonts as well as ASCII.
TFT Display
The display of this model is an upgrade in image quality, response time, and resolution over those still using monochrome or STN-type LCD screens. It also comes with a powerful CCFL backlight. This makes the images displayed by this model clear and easy to see, even in difficult viewing angles or lighting conditions. The GP2600-TC41-24V offers up to 256 no-blink colors on its TFT color LCD display. This reduces to 64 colors with 3-speed blink. The unit has an effective display area of 9.69 inches by 7.27 inches and has four levels of brightness control.
Helpful Features
The GP2600-TC41-24V easily supports report generation through its printer and barcode reader connection ports. Additionally, the unit has the capability to support 4-channel video through an optional module. This can provide machine monitoring and surveillance to your industrial site. The enclosure of the GP2600-TC41-24V rates at IP65F, which makes it a good choice for environments where solids, water, or oil will be prevalent enough to pose a threat to your machinery. It is important to note that this unit runs on a 24 VDC power input and draws 50 watts or less of power.
