Professional Corrugated Flexo Printing Slotting Die Cutting Machine
Muiti-color Flexo Printing Slotting Die Cutting Machine Features：
·This machine is designed and made to high quality and safety standard,with the advantages of high speed, auto control and quick order shift.
·Auto high quality materials and parts.
·Well hardened and ground transmission gears, hardness more than 60(HRC).
·Vacuum transfer system used in all printing sections.
·Use expansion sets tight link to reduce abrasion of the shaft,keep precision of the machine for long years.
·PLC control system with touch screen control.
·Able to save order,speed up the order shift.
·All electronic and pneumatic components are with European standards.
·Able to shift order of the idle Printing Section under production.
·Able to facilitate the production management.
Auto Flexo Printing Slotting Rotary Die Cutting Machine Specification：
|
Data/Model
|
900x2000
|
900x2400
|
1200x2000
|
1200x2400
|
|
Printing Speed(m/min)
|
200
|
200
|
200
|
200
|
|
Max Machine Speed(pcs/min)
|
350
|
300
|
250
|
250
|
|
Max Feeding Size(mm)
|
880x2000
|
880x2400
|
1180x2000
|
1180x2400
|
|
Min Feeding Size(mm)
|
280x640
|
280x640
|
320x700
|
320x700
|
|
Skip Feeding(mm)
|
1100x2000
|
1100x2400
|
1500x2000
|
1500x2400
|
|
Max Printing Area(mm)
|
800x2000
|
800x2400
|
1150x2000
|
1150x2400
|
|
Thickness of Printing Plate(mm)
|
7.2
|
7.2
|
7.2
|
7.2
|
|
Min Panel(mm) Slot Type L.
|
240x80x240x80
|
240x80x240x80
|
260x90x260x90
|
260x90x260x90
|
|
Max Slotting Depth(mm)
|
250
|
250
|
320
|
320
|
|
Max Thickness of Sheet(mm)
|
8
|
8
|
12
|
12
|
|
Dimension(LxWxH)
T
F
|
T:14374x5770x3200
F:15674x5770x3200
|
T:14374x6170x3200
F:15674x6170x3200
|
T:15732x5870x3500
F:17232x5870x3500
|
T:15732x6270x3500
F:17232x6270x3500
|
Packaging details:
Package/piling: Good hard steel pallet strengthen and fixed, packing with transparent plastic-film, class and numbering, cannot extrusion and stacker.
Port: Guangzhou/Shenzhen
